21 −２ CONNECTINGNETWORKCABLES
Toenablenetworkplay,thehubsinsideeachofthegamemachinesinvolvedmustbeconnected
withnetwork(LAN)cables.Connectthehubinsideoneofthemachinestothehubsineachof
theothermachinesusingLANcables.Thereisnoneedtoconnecttheothermachinestoeach
other.
DonotconnectLANcablestogamemachineswhentheyarenotusedfornetworkplay.
ThefollowingprocedurerequirestheincludedLANcables,themasterkey,aM4-size
screwdriver,anda24mmdiameterspanner.
① Turnoffthepowerandunplugthepowercordfromtheoutlet.Placethepowercordsoasnotto
damageitwhileworking.
②UsingSection8ofthismanualasreference,movethemachinessothattheyarelinedup.Leave
enoughspaceonthefrontlidsideofthemachinetoperformtherestoftheoperationsinthis
procedure.
FRONTLID
PHOTO21.2a
④ Loosen2ofthetrussscrewsonthecable
coverandshiftthecoverdownward.
CABLECOVER
PHOTO21.2b
③ Removethe6trussscrewssecuringthefrontlidto
thefrontofthemachineandthenremovethelid.
TRUSSSCREW(6),black
M4×8
TRUSSSCREW(4),black
M4×8
