18 −３ DRIVEBOARD7-SEGMESSAGES
Thissectiondealswiththeinteriorofthemachinewhenelectriccurrentis
flowingthroughit.Avoidaccidentallytouchinganypartofthemachine.
Doingsomayresultinelectricshockand/orshortcircuits.
Donotchangethevaluesofthedipswitchesonthemachine's
motherboardfromtheirfactorysettings.Doingsowilldisruptthe
machine'sfunctionswhenusingoroperatingthemachine.
Ifanerrorisdetectedduringtheinitializationprocessthatoccurswhenthemachineisturned
on,amessagewillbedisplayedonthedriveboard's7-segmentdisplay.Thesemessagesare
describedbelow;usethemasreferencetoidentifyandresolvetheproblem.
ThedriveboardislocatedontheassemblyI/Oboardinthebaseinterior.
Withthepowerturnedon,removethe2trussscrewssecuringfloorLandthenremovethefloor
toreachtheassemblyI/Oboard.
FLOORL
PHOTO18.3a
DRIVEBOARD
PHOTO18.3b ASSYI/OBD
TRUSSSCREW(2)
M4×8,chrome
