16. REPLACING THE FLUORESCENT LAMPS
● Whenperformingwork,besuretoturnpoweroff.Workingwithpower
oncancauseelectricshockandshortcircuithazards.
●TheFluorescentLamp,whenitgetshot,cancauseburn.Bevery
carefulwhenreplacingtheFluorescentLamp.
Becarefulwhenhandlingtheplasticparts.Failuretoobservethismay
causeinjuryduetodamageorfragmentsresultingfromdamage.
Thereis1fluorescentlampinsideeachofthelightboxeslocatedonthetopandbottomofthe
backofthecabinet.
① Turnoffthepower.
② Removethe8trussscrewsandthenremovethe
upperlightboxplate.
③ Oncetheupperlightboxplatehasbeenremoved,
thelampcanbereplaced.
LIGHTBOXPLATEUPPER
PHOTO16a
PHOTO16b
TRUSSSCREW(8)
M4×8,flatwasherused,chrome
FLUORESCENTLAMP20WWHITE:390-5251-20-01
GLOWBULB:390-5638-1P
UpperLamp
