− 140 −
① Turnoffthepower.
② Removethe8trussscrewsandthen
removethelowerlightboxplate.
PHOTO16c
③Oncethelowerlightboxplatehasbeen
removed,thelampcanbereplaced.
LIGHTBOXPLATELOWER
PHOTO16d
LowerLamp
TRUSSSCREW(8)
M4×8,flatwasherused,chrome
FLUORESCENTLAMP20WWHITE:390-5251-20-01
GLOWBULB:390-5638-1P
