12. MAINTAINING THE BASE INTERIOR
●Inordertopreventanelectricshockandshortcircuit,besuretoturn
poweroffbeforeperformingworkbytouchingtheinteriorpartsofthe
product.
● Becarefulnottodamagethewires.Damagedwiresmaycause
electricshockorshortcircuitorpresentafirerisk.
● Donottouchundesignatedplaces.Touchingplacesnotdesignated
cancauseelectricshockorshortcircuit.
● Thisworkshouldbeperformedbythesitemaintenanceindividualor
otherskilledprofessional.Performingworkbynon-technicalpersonnel
cancauseelectricshockhazard.
● DonotperformworkotherthanthosespecifiedinthisManualinorder
topreventaccidentsduringperformingworkandoperationafter
performingwork.PerformingworknotspecifiedinthisManualmay
requirespecialtrainingforthisproduct.Ifperformingworkotherthan
thosestatedinthismanualisrequiredforrepair,contacttheoffices
hereinstatedinthismanualorwhereyoupurchasedtheproductfrom
andaskforrepairorinquirehowtorepair.
● Beverycarefulwhensoldering.Handlingasolderingironcarelessly
mayresultinafireoraburn.
● Beextremelycarefulwhenheatingtheheat-shrinkabletube.Failureto
dosomayresultinafireorburns.
●Aftermakingadjustmentsorreplacements,checkthesurroundingarea
beforeturningthepoweron.Themachinewillautomaticallygothrough
initializationafterthepoweristurnedon,andanypersonsinthe
vicinitymaybestruckand/orknockeddownbythemovingseat.
● Requestsformaintenanceoftheseatmotionmechanismshouldbe
directedtotheofficelistedinthismanualoryourretailer.Attemptsto
performmaintenancebypersonsotherthanspeciallytrained
techniciansmayresultininjurytothepartyperformingthe
maintenanceand/ortoplayersduringproductoperation.
● Becarefulnottotraphandsorfingersinsidemechanicalparts.Doing
somayresultinbrokenbonesandotherseriousinjury.
Whenadjustingorchangingthevariableresistor,setthevariableresistor
valuesontheVolumeSettingsscreenandcheckthevaluesontheInput
TestscreeninTestmode.
IfdirectionalcontrolresponseislessthanidealandadjustingthesettingsontheVolume
SettingsscreeninTestmodehasnoeffect,theproblemismostlikelyduetoanincorrectly
engagedgearinthesteeringVRorabrokenvariableresistor.
Followthestepslistedbelowtocorrectthegearengagementorreplacethevariableresistor.
Inthecaseoffaultymovementintheseat,thesourceoftheproblemismostlikelyan
incorrectlyengagedgearorbrokenvariableresistorintheRollVR.
ThesteeringVRandRollVRarebothlocatedontheACunitsideofthebaseinterior.
