122
Loosenthe2screwsholdingthesteeringVRbracketinplaceanddisengagethegear.
 STEERINGVRBRACKET 
PHOTO12.1b
EngagethegearsothattheD-cutsideoftheVRaxleislevelandfacingdownwardwhenthe
steeringunitisinthestraightposition(seeFigure12-1).
Tightenthe2screwsholdingthebracketinplace.
AdjustthevariableresistorsettingsontheVolumeSettingsscreen(see10-3G).
⑦Checktomakesurethe"STEERINGX"valueontheInputTestscreeniswithintherange80H
±8Hwhenthesteeringunitisinthestraightposition.
 SCREW(2)         
 M4×8,w/flat&springwashers
