① Turnoffthepower.
② Removethe6trussscrewsholdingthefrontlidofthebaseinplaceandthenremovethelid.
③RemovethesteeringVRunit.Unplugtheconnectorsandremovethe2screwsholdingthe
steeringVRbracketinplace.
STEERINGVRBRACKET
CONNECTOR
PHOTO12.1c
④Loosenthe2socketscrewsholdingthegearinplaceanddisengagethegearfromtheVRaxle.
PHOTO12.1d
GEAR
HEXAGONSOCKETSCREW(2)
M3×6
REPLACEMENTPROCEDURE
SCREW(2)
M4×8,w/flat&springwashers
