IMPORTANT
Do not overtighten the screws which secure the Billboard Header in place. The Billboard Header is made from an
acrylic and is very fragile. Over tightening the xing screws may cause damage.
1
Fit and secure the Billboard to the top of the Display Cabinet in the position shown using M5x12 M SCR
PAN PAS (2). The xings are already placed within the locations and covered by an acyrlic protector. Both
will need to be removed prior tting.
6-1-2 INSTALLING THE BILLBOARD HEADER
Billboard Header
Fixing Points
Do not overtighten
• To perform work safely and securely, be sure to prepare a step which is in a
safe and stable condition. Performing work without using a step may lead to
injury or damage to components.
To Next Page
