9-3-6 LED ADJUSTMENT
Conduct adjustment of the full-colour LEDs surrounding the monitor.
LED ADJUSTMENT
MAX R *
MAX G *
MAX B *
SET DEFAULT
COLOUR PATTERN *
EXIT
BOARD STATE READY
SELECT WITH SERVICE
AND PRESS TEST BUTTON
LED ADJUSTMENT screen
■
Controls
- Press the SERVICE Button to select menu item.
- Press the TEST Button to change the value of the selected item.
- Select EXIT and press the TEST Button to return to the GAME TEST MENU screen.
■
Menu Items
MAX R
Adjusts the brightness of red LEDs from 0.1 to 1.0 in gradients of 0.1.
(Default setting: 1.0)
MAX G
Adjusts the brightness of green LEDs from 0.1 to 1.0 in gradients of 0.1. (Default set-
ting: 0.9)
MAX B
Adjusts the brightness of blue LEDs from 0.1 to 1.0 in gradients of 0.1.
(Default setting: 0.7)
SET DEFAULT
Returns the LED color shades to their defaults.
COLOR PATTERN
Switches the LED display color pattern: WHITE; BLUE; RED; GREEN; BLACK TO
WHITE.
BOARD STATE
Displays status of LED board.
READY
Usable status
NOT READY
Undergoing formatting status
NO LED
BOARD
Unusable status
