4.2 SEMATIC DRIVE SYSTEM© SET-UP AND INCOMING/OUTGOING SIGNALS FROM THE DOOR
CONTROLLER
1 Magnetic switches
2 Safety chains
3 Main Lift Controller
4 Photocells or Detector
