• The parameter “Comfort” determines acceleration value or deceleration value that the controller has to comply
with while changing profile velocity. This parameter is important to establish the panel fluidness movement.
The display shows the parameter value expressed in percentage and below the real value of the parameter;
• At the end of the parameters modifications the diagram will adapt and will show the new speed profile;
• Press key F2 (<> - ><) to check the door operation with the new set profile and, by performing an opening
cycle, this will update the indicator of time necessary to carry out the opening cycle with the new set profile;
• Press key F3 (NEXT) to carry on the profile setting with the CLOSING PARAMETERS setting; the same
operations must be followed as above in relation to the OPENING PARAMETERS setting;
• Press key F1 (BACK) to the previous menu;
7.5 OPTION “ADVANCED SETTINGS”
• Connect the handset to RJ45 connector
• If necessary, using keys  and  choose the required language and confirm with the “OK” key
• Using keys  and  run through the MAIN MENU and choose PROFILE SETTING;
• Press the “OK” key to confirm the option
• On the display the following options are viewed:
– FAST SETTING
– REVERSING SYSTEM
– ADVANCED SETTINGS
– RESERVED AREA
• Using keys  and  run through the menu “PROFILE SETTING” and choose the option ADVANCED SETTING
• Using the “OK” key, confirm the option
After confirming the choice by pressing the “OK” key, a 5-code password is required on the display. The factory
default access code is 00001.
Use keys á and  to move to different digits and to select the necessary coded digit use keys  and ; Press
OK at the end.
The following options are viewed on the display:
• OPENING PARAMETERS
• CLOSING PARAMETERS
• CHANGE PASSWORD
• RESET SPEED
• INPUT LEVELS LOGIC
• DELAY Ra TO IREST OPENING (ONLY FOR DIGIDOOR EMULATION)
• DELAY Lc TO IREST CLOSING (ONLY FOR DIGIDOOR EMULATION)
Using keys  and  run through the menu and choose the required option
• Using the “OK” key, confirm the option
• The following options are available:
– “BACK”: press key F1 to restore the MAIN MENU
– “MENU”: press key F3 to restore the MAIN MENU
7.5.1 Option “Opening Parameters”
The following options are viewed on the display:
• LOW START SPEED
• ACCELERATION START
• ACCELERATION
• HIGH SPEED
• OFFSET DECELERATION
• DECELERATION
• LOW SPEED
• FITTINGS
