General option
811-000-000 SDS© DC-PWM Compatible • Edition 25 March 2016
8 GENERAL OPTION
• Connect the handset to RJ45 connector;
• If necessary, using keys  and  choose the required language and confirm with the “OK” key
• Using keys  and  run through the MAIN MENU and choose GENERAL OPTIONS
• Press OK to confirm the choice
• The GENERAL OPTION menu allows the Door Controller to operate by means of the following parameter
options:
– REVERSING SYSTEM
– MAIN LIFT CONTROLLER TEST
– NO MLC SIGNAL
– MLC INPUT ALARM
– LIMITED DOOR REVERSAL
– CAR DOOR LOCKING DEVICE
– GLAZED PANELED DOORS
– AUX OUTPUT RELAY
– PROTECTIVE DEVICE LOGIC
– EMULATION TYPE
These parameter meanings and settings are detailed in the following paragraphs.
8.1 REVERSING SYSTEM SETTING BY MEANS OF THE HANDSET
• See § 6.1 (pg. 21) for the meaning of this parameter
• Using keys  and  run through the GENERAL OPTIONS and choose the option REVERSING SYSTEM
• Press the “OK” key to confirm the choice
• The following options are viewed on the display:
– INTERNAL
– EXTERNAL
• Using keys  and  choose the required option and press the “OK” key to confirm it
• The display shows the confirmed option and restores the menu GENERAL OPTIONS
• The following options are available:
– “BACK”: Press key F1 to restore the menu GENERAL OPTIONS
– “MENU”: Press key F3 to restore the MAIN MENU
8.2 ACTIVATION OF THE MAIN LIFT CONTROLLER TEST BY MEANS OF THE HANDSET
• See § 6.4 (pg. 21) for the meaning of this parameter
• Using keys  and  run through the GENERAL OPTIONS and choose the option MAIN LIFT CONTROLLER TEST
• Press the “OK” key to confirm the choice
• The following options are viewed on the display:
– WHEN MOVING
• The display shows the confirmed option and restores the menu GENERAL OPTIONS
• The following options are available:
– “BACK”: Press key F1 to restore the menu GENERAL OPTIONS
– “MENU”: Press key F3 to restore the MAIN MENU
8.3 ACTIVATION OF THE MAIN LIFT FAILURE BY MEANS OF THE HANDSET
• See § 6.4.1 (pg. 21) for the meaning of this parameter
• Using keys  and  run through the GENERAL OPTIONS and choose the option NO MLC SIGNAL
• Press the “OK” key to confirm the choice
• The following options are viewed on the display:
– IMMEDIATELY STOP
• The display shows the confirmed option and restores the menu GENERAL OPTIONS
• The following options are available:
