Signals to/from the door controller
811-000-000 SDS© DC-PWM Compatible • Edition 25 March 2016
-
Note: Sematic Drive System© controller may be used also with incoming signal from the Main Lift Controller with
voltage range between 6 and 24 Vdc.
To use this feature:
• Remove the shunt between 37-38 connector pins
• Connect the 38 connector pin at the 0V DC external incoming signal Power supply
INCOMING SIGNALS FROM THE DOOR CONTROLLER
Signal Connector Pins Contact type & normal state Note
Opening control Ka
(coming from the Main Lift
Controller)
Connector pins
5-15
These connections require dry
(voltage free) contacts (contact
open when inactive)
When the Door Controller is
installed on a Front & Rear
entrance car, it is important that
the opening and closing
commands have no common
contacts between the two doors.
Shielded, Grounded Wire Highly
Recommended
Closing control Kc
(coming from the Main Lift
Controller)
Connector pins
3-15
These connections require dry
(voltage free) contacts (contact
open when inactive)
Forced closing control at low
speed Kb
Connector pins
15-22
These connections require dry
(voltage free) contacts (contact
open when inactive)
The main lift controller may signal
the forced closing when the
photocell (or similar device) shall
be made inoperative due to a
failure, or after several door
closing failures.
Re-opening control Kn Connector pins
15-23
These connections require dry
(voltage free) contacts (both
logics available)
See 4.1 & 4.2 for the connection
to the door controller
Closing limit switch contact Lc Connector pins
15-39
These connections require dry
(voltage free) contacts (contact
open when door is closed)
From the operator closing limit
magnetic switch
Closing slow down contact La Connector pins
15-42
These connections require dry
(voltage free) contacts (contact
open when door is open)
From the operator closing limit
magnetic switch
Opening limit switch contact Rc Connector pins
15-40
These connections require dry
(voltage free) contacts (contact
open when inactive)
From the operator opening limit
magnetic switch (Nnot used for
DIGIDOOR compatibility).
Opening slow down contact Ra Connector pins
15-41
These connections require dry
(voltage free) contacts (contact
open when inactive)
From the operator opening slow
down magnetic switch
Handset (Optional) Connector RJ45 (B)
