For each of the above listed parameter the parameter name is displayed at the top, the current value is displayed
at the bottom with the relevant unit measure; the up/down arrow keys allow changing the current value.
• The following options are available:
– “BACK”: press key F1 to restore the MAIN MENU
– F2 KEY: to open and close the door, to test the modified profile
– “DRAW”: press key F3 to update the speed profile drawing
7.5.2 Option “Closing Parameters”
The following options are viewed on the display:
• LOW START SPEED
• ACCELERATION START
• ACCELERATION
• HIGH SPEED
• OFFSET DECELERATION
• DECELERATION
• LOW SPEED
• FITTINGS
For each of the above listed parameter the parameter name is displayed at the top, the current value is displayed
at the bottom with the relevant unit measure; the up/down arrow keys allow changing the current value.
• The following options are available:
– “BACK”: press key F1 to restore the MAIN MENU
– F2 KEY: to open and close the door, to test the modified profile
– “DRAW”: press key F3 to update the speed profile drawing
7.5.3 Option “Change Password”
This option allows the user to change access passwords; input the new password as follows:
Select the desired code digit using keys  and ; Use keys á and  to move to different digits. Press OK at the
end.
7.5.4 Option “Reset speed”
This option allows the user to change the speed at wich the controller operate the initial reset cycle.
Select the desired reset speed using keys  and . Press OK at the end.
7.5.5 Option “Input levels logic”
This option allows the user to change the Input/Output levels logic, to interface correctly the main lift controller
• On the display are viewed all the input/output signals: the user can change the logic if needed;
• H (High Level) means that the signal will be activate by +24V
• L (Low level) means that the signal will be activate by 0V
• Using keys  and  select the required input/output and using á or  select the required logic (H or L)
• Press the "OK" key to confirm levels logic settings
For the Digidoor Interface connection verify that:
INPUT
Ka  L
Kc  L
Kb  L
Kn  H (to verify if it's needed)
OUTPUT
La  H (to verify if it's needed an L - Low level logic)
Lc  H (to verify if it's needed an L - Low level logic)
