Upgrade from LMDC 2010/11 controller
811-000-000 SDS© DC-PWM Compatible • Edition 25 March 2016
15 UPGRADE FROM LMDC 2010/11 CONTROLLER
• Eliminate the transformer 220/24 V with all its cables because the new SDS is fitted with an in-built switching
transformer
• Disconnect all the connectors on the controller to be substituted and connect them again to the new controller
using the connectors-adatpers Code nr. B066AATX; this way no wiring operation is necessary and the
substitution is quick and easy.
• If the connectors-adapters Code nr. B066AATX are not available: disconnect the wires from the old connectors
and connect them again following the correspondence given in the underneath table
• Connect the 220 Vac input to the SDS controller by means of the feeding cable supplied code no. E066AAWX-
A
• Select option EMULATION LM-DC 2010 or EMULATION LM-DC 2011 from the Menu General Option (see § 8.10
(pg. 32)) or programm parameter 22 using the keys on the frontal panel (05 o 06, see also § 5.3 (pg. 19)).
• Check the correct functioning
LM-DC 2010/11 TERMINALS FUNCTION SEMATIC SDS Rel. 3
DC COMPATIBILE
LS1 Photocell or similar devices 24 Vdc COM 15
LS2 Photocell or similar devices control input 23
3 Kc closing control 3
5 Ka opening control 5
15 COM 24 Vdc 15
6 Ra and Rc opening and closing slow down
COM
15
6 Ra and Rc opening and closing slow down
COM
15
11 Ra opening slow down Input signal 41
13 Ra and Rc opening and closing slow down
COM
42
16 La Opening limit switch input contact
(from the magnetic switch)
40
17 La Opening limit switch COM (from the
magnetic switch)
15
18 Lc Closing limit switch input contact
(from the magnetic switch)
39
19 Lc Closing limit switch COM (from the
magnetic switch)
15
+B Auxiliary emergency power supply +
-B Auxiliary emergency power supply -
9 Motor power 43
10 Motor power 44
