Functions available
811-000-000 SDS© DC-PWM Compatible • Edition 25 March 2016
6.7 AUX OUTPUT RELAY
This option can be used to signal the achievement of a particular opening distance (pre-set) or as Gong while
opening (device not supplied by Sematic).
6.7.1 Space Percentage
If set, this option allows the Aux Output Relay contacts to send a signal during door opening that relates to a pre-
set distance percentage (in comparison to the total door opening) and a signal during the door closing up to the
same opening percentage.
6.7.2 Gong While Opening
If set, this option allows the Aux Output Relay contacts to send a signal during the door opening (to a device not
supplied by Sematic).
6.8 FORCED CLOSING (NUDGING)
If the main lift controller operates with a disabling photocell circuit (or similar device), after several failed attempts
at closure, it is possible to command the closure of the doors in low speed (forced closing), by closing the 15-22
connector pins by means of a relay (voltage free contact).
During the closing cycle the connector 21 (Gnd) and the connector 15 (+24 V) are activated for the direct use of
a 24 Vdc max 100 mA buzzer (device not supplied by Sematic) or adequate relay.
6.9 PROTECTIVE DEVICE LOGIC KN
This parameter sets the logic on the protective device input Kn (Photocells, optical barrier...); its default value (0)
means that the contact is open in normal condition and it is closed to signal the presence of an obstacle; the
alternative value (1) reverses the logic, i.e. the contact is closed in normal conditions and it opens to signal the
presence of an obstacle.
6.10 EMULATION TYPE
SDS DC-COMPATIBLE controller may replace different kind of old controllers. Usig this parameter is possible to
select requested controller emulation type within the following list:
• Emulation F28
• Emulation F29
• Emulation DIGIDOOR 1Nm
• Emulation DIGIDOOR 2Nm
• Emulation LM-DC 2010
• Emulation LM-DC 2011
It's possible to select the emulation type with the SDS Handset ( § 8.10 (pg. 32) ) or in programming mode
“PROG” (§ 5.3 (pg. 19)).
WARNING: if the selected logic is Kn N/C on obstruction open (contact opens to signal the presence of an
obstacle) and is used only one protective device input (15-23) terminals for photocells, 30-31-32-33
terminals for direct connection of protective barriers), the other input must be shorted. For example if N/C
logic protective barriers are connected to 31-32-33 terminals, 23 and 15 terminals must be shorted; if N/
C logic photocells are connected to 23 and 15 terminals, 31 and 32 terminal must be shorted.
Note: if Digidoor controller compatibility is requested please verify the Main Lift Controller signals logic and
voltage rate.
If these values don't fit with the range and the logic explained in § 4 (pg. 12), it is possible to install the
Sematic Interface Kit cod. B066AAPX following the enclosed instruction.
