Upgrade from F28/F29 controller
39
811-000-000 SDS© DC-PWM Compatible • Edition 25 March 2016
13 UPGRADE FROM F28/F29 CONTROLLER
• Eliminate the transformer 220/24 V with all its cables because the new SDS is fitted with an in-built switching
transformer
• Disconnect the wires from the old connectors and wire them again according to the correspondence given in
the underneath table.
• Connect the 220 Vac input to the SDS controller by means of the feeding cable supplied code no. E066AAWX-
A
• Select option EMULATION F28 or EMULATION F29 from the Menu General Option (see chapter 8.10) or
programm parameter 22 using the keys on the frontal panel (01 o 02, see also § 5.3 (pg. 19)).
• Check the correct functioning
F28-29C TERMINALS FUNCTION SEMATIC SDS Rel. 3
DC COMPATIBILE
1 IM reversing system N/C signal 1
2 IM reversing system N/O signal 2
4 IM reversing system COM signal 4
3 Kc closing control 3
5 Ka opening control 5
15 24 Vdc COM 15
6 Ra and Rc opening and closing slow down
COM
15
6 Ra and Rc opening and closing slow down
COM
15
11 Ra opening slow down Input signal 41
13 Rc closing slow down Input signal 42
9 Motor power 43
10 Motor power 44
7 24 Vac power NOT CONNECTED
8 24 Vac power NOT CONNECTED
+ Auxiliary emergency power supply +
- Auxiliary emergency power supply -
20 Buzzer 15
21 Buzzer 21
22 NOT CONNECTED
OPERATOR TERMINALS FUNCTION SEMATIC SDS Rel. 3
DC COMPATIBILE
16 OUT La Opening limit switch output contact
(to the main lift controller)
16
17 OUT La Opening limit switch output contact
(to the main lift controller)
17
18 OUT Lc Closing limit switch output contact (to
the main lift controller)
18
19 OUT Lc Closing limit switch output contact (to
the main lift controller)
19
