General option
811-000-000 SDS© DC-PWM Compatible • Edition 25 March 2016
• The following options are available:
– “BACK”: Press key F1 to restore the menu GENERAL OPTIONS
– “MENU”: Press key F3 to restore the MAIN MENU
8.8 AUX OUTPUT RELAY SETTING BY MEANS OF THE HANDSET
• See § 6.7 (pg. 22) for the meaning of this parameter
• Using keys  and , run through the GENERAL OPTIONS and choose the option AUX OUTPUT RELAY
• Press the “OK” key to confirm the choice
• The following options are viewed on the display
– OFF
– GONG WHILE OPENING
– SPACE PERCENTAGE
• Using keys  and , choose the required option and press the “OK” key to confirm it; If the option “SPACE
PERTENTAGE” is chosen, the present space percentage is viewed on the display. To modify it, use key  and
 as shown on the display right side. Confirm the required option by pressing the “OK” key. The display shows
the confirmed option and restores the menu GENERAL OPTIONS
• The following options are available:
– “BACK”: Press key F1 to restore the menu PROFILE SETTING
– “MENU”: Press key F3 to restore the MAIN MENU
8.9 PROTECTIVE DEVICE LOGIC KN SETTING BY MEANS OF THE HANDSET
• See § 6.9 (pg. 22) for the meaning of this parameter
• Using keys  and , run through the GENERAL OPTIONS and choose the PROTECTIVE DEVICE LOGIC option
• Press the “OK” key to confirm the choice
• The following options are viewed on the display:
– ON OBSTRUCT. : CLOSED
– ON OBSTRUCT. : OPEN
• Using keys  and , choose the required option and press the “OK” key to confirm it
• The display shows the confirmed option and restores the menu GENERAL OPTIONS
• The following options are available:
– “BACK”: Press key F1 to restore the menu PROFILE SETTINGS
– “MENU”: Press key F3 to restore the MAIN MENU
8.10 EMULATION TYPE
• See § 6.10 (pg. 22) for the meaning of this parameter
• Using keys  and , run through the GENERAL OPTIONS and choose the EMULATION TYPE Option
• Press the “OK” key to confirm the choice
• The following options are viewed on the display:
– Emulation F28
– Emulation F29
– Emulation DIGIDOOR 1Nm
– Emulation DIGIDOOR 2Nm
– Emulation LM-DC 2010
– Emulation LM-DC 2011
• Using keys  and , choose the required option and press the “OK” key to confirm it
• The display shows the confirmed option and the controller operates a reset coming back to the MAI MENU
