Upgrade from F28/F29 controller rel. 2.0 Controller
41
811-000-000 SDS© DC-PWM Compatible • Edition 25 March 2016
14 UPGRADE FROM F28/F29 CONTROLLER REL. 2.0 CONTROLLER
• Eliminate the transformer 220/24 V with all its cables because the new SDS is fitted with an in-built switching
transformer
• Disconnect all the connectors on the controller to be substituted and connect them again to the new controller
using the connectors-adatpers Code nr. B066AASX; this way no wiring operation is necessary and the
substitution is quick and easy.
• If the connectors-adapters Code nr. B066AASX are not available: disconnect the wires from the old connectors
and connect them again following the correspondence given in the underneath table
• Connect the 220 Vac input to the SDS controller by means of the feeding cable supplied code no. E066AAWX-
A
• Select option EMULATION F28 or EMULATION F29 from the Menu General Option (see chapter 8.10) or
programm parameter 22 using the keys on the frontal panel (01 o 02, see also § 5.3 (pg. 19)).
• Check the correct functioning
F28-29 Rel. 2.0 TERMINALS FUNCTION SEMATIC SDS Rel. 3
DC COMPATIBILE
1 IM reversing system N/C signal 1
2 IM reversing system N/O signal 2
4 IM reversing system COM signal 4
3 Closing control Kc 3
5 Opening control Ka 5
15 COM 24 Vdc 15
16 OUT Opening limit switch output contact La (to the main lift controller) 16
17 OUT Opening limit switch output contact La (to the main lift controller) 17
18 OUT Closing limit switch output contact Lc (to the main lift controller) 18
19 OUT Closing limit switch output contact Lc (to the main lift controller) 19
6 Opening and closing slow down Ra and Rc COM 15
6 Opening and closing slow down Ra and Rc COM 15
11 Opening slow down Ra Input signal 41
13 Closing slow down Rc Input signal 42
16 IN Opening limit switch contact La (from the magnetic switch) 40
17 IN Opening limit switch contact La (from the magnetic switch) 15
18 IN Closing limit switch contact Lc (from the magnetic switch) 39
19 IN Closing limit switch contact Lc (from the magnetic switch) 15
9 Motor power 43
10 Motor power 44
7 24 Vac power NOT CONNECTED
8 24 Vac power NOT CONNECTED
+ Auxiliary emergency power supply +
- Auxiliary emergency power supply -
20 Buzzer 15
21 Buzzer 21
22 Forced closing (nudging) input contact 22
