Upgrade from controllers previous to F28/F29 controller (Controller type: ASC 10/20, ADC10/11, SEM10/11,
811-000-000 SDS© DC-PWM Compatible • Edition 25 March 2016
11 UPGRADE FROM CONTROLLERS PREVIOUS TO F28/F29 CONTROLLER
(CONTROLLER TYPE: ASC 10/20, ADC10/11, SEM10/11, LMDC 10/11) F28/29 B
• Eliminate the transformer 220/24 V with all its cables because the new SDS is fitted with an in-built switching
transformer
• Cut the old terminal connection because the new connector is provided with cables with screws
• The wires (numbered) must be stripped and wired into the four connectors of the compatible SDS Controller
following the correspondence given in the underneath table:
• Connect the 220 Vac input to the SDS controller by means of the feeding cable supplied code no. E066AAWX-A
• Select option EMULATION F28 or EMULATION F29 from the Menu General Option (see chapter 8.10) or
programm parameter 22 using the keys on the frontal panel (01 o 02, see also § 5.3 (pg. 19)).
• Check the correct functioning
CONNECTOR FUNCTION SEMATIC SDS Rel. 3
DC COMPATIBILE
1 IM reversing system N/C signal 1
2 IM reversing system N/O signal 2
3 Kc closing control 3
4 IM reversing system COM 4
5 Ka opening control 5
6 Ra and Rc opening and closing slow down COM 15
7 24 Vac power NOT CONNECTED
8 24 Vac power NOT CONNECTED
9 motor power 43
10 motor power 44
11 Ra opening slow down Input signal 41
12 NOT CONNECTED
13 Rc closing slow down Input signal 42
14 NOT CONNECTED
15 24 Vdc COM 15
OPERATOR TERMINALS FUNCTION SEMATIC SDS Rel. 3
DC COMPATIBILE
16 OUT La Opening limit switch output contact (to the main lift controller) 16
17 OUT La Opening limit switch output contact (to the main lift controller) 17
18 OUT Lc Closing limit switch output contact (to the main lift controller) 18
19 OUT Lc Closing limit switch output contact (to the main lift controller) 19
MAGNETIC BISTABLE SWITCHES
FOR OPENING AND
CLOSING LIMITS
FUNCTION SEMATIC SDS Rel. 3
DC COMPATIBILE
16 IN La Opening limit switch input contact (from the magnetic switch) 40
17 IN La Opening limit switch COM (from the magnetic switch) 15
18 IN Lc Closing limit switch input contact (from the magnetic switch) 39
19 IN Lc Closing limit switch output contact (to the main lift controller) 15
Warning!
If in the old drive the magnetic switches La-Opening Limit and Lc-Closing Limit are directly connected to
the main lift controller, disconnect and re-connect them at the new SDS Rel.3 DC COMPATIBILE controller
39 - 15 - 40 - 15 input terminals (as shown in the table). Connect SDS Rel. 3 DC COMPATIBILE La and Lc
outputs to the main lift controller, at terminals 16 - 17 - 18 - 19.
