Instruction without handset
811-000-000 SDS© DC-PWM Compatible • Edition 25 March 2016
-
The following table contains the available parameters, the relevant codes, the description and the
allowed modification range:
Param. codes Default Parameter Range Note
00 00 Reversing system choice 00, 01 00-> Internal
01-> External
01 00 Main Lift Controller Test 00, 01, 02 00-> When moving
01-> Moving + Parking
02-> Off
02 00 No MLC signal 00, 01, 02 00 -> Instant Stop
01 -> Low Speed to Stop
02-> Low speed Cycle
03 00 MLC Input Alarm 00, 01 00 -> Off
01 -> On
04 00 Limited Door Reversal Effects 00, 01 00 -> Off
01 -> On
05 00 Car door locking device 00, 01 00 -> Off
01 -> On
06 00 Glass doors 00, 01 00 -> Off
01 -> On
07 00 Aux Output Relay 00, 01, 02,
03
00 -> Off
01 -> Gong While opening
02 -> According to % of space
03 -> Termic Alarm signal
08 00 Space Percentage (Percentage of
the available space
to operate the AUX relay)
00...99 00..99% (00 = closing limit)
09 66 Reversing force setting 00...99 10-150 N (10-135 N U.S. version)
10 33 Opening High Speed 01...99
11 50 Opening Low Speed 01...99
12 50 Opening "comfort" 01...99
13 30 Closing High Speed 01...99
14 50 Closing Low Speed 01...99
15 80 Closing "comfort" 01...99
16 - Not Used -
17 - Not Used -
18 - Not Used -
21 00 Protective Device Logic Kn 00, 01 00 -> N/O, on obstruction closed
01 -> N/C, on obstruction open
22 01 Emulation Type 01, 02, 03,
04, 05, 06
01 ->Emulation F28
02 -> Emulation F29
03 -> Emulation Digidoor 1 Nm
04 -> Emulation Digidoor 2 Nm
05-> Emulation LM-DC 2010
06 -> Emulation LM-DC 2011
23 00 Ka, Kc, Kb inputs logic (see also §
7.6 (pg. 29))
00, 01 00 -> Ka, Kc, Kb inputs activated
by +24V (high level logic)
01 ->Ka, Kc, Kb inputs activated
by 0V (low level logic)
