11.4.3 GnssReadResults

The command GnssReadResults( ) allows to retrieve the last GNSS results.

Table 11-6: GnssGetResultSize Command

Byte 0 1

Data from Host 0x04 0x0C

Data to Host Stat1 Stat2

Table 11-7: GnssGetResultSize Response

Byte 0 1 2

Data from Host 0x00 0x00 0x00

Data to Host Stat1 ResultSize (15:8) ResultSize (7:0)

Table 11-8: GnssReadResults Command

Byte 0 1

Data from Host 0x04 0x0D

Data to Host Stat1 Stat2

Table 11-9: GnssReadResults Response

Byte 0 1 2 3 …

Data from Host 0x00 0x00 0x00 0x00 0x00

Data to Host Stat1 ResultsByte1 ResultsByte2 ResultsByte3 ResultsByteN
