15.4 Wi-Fi Configuration / Status Operations

Table 15-4: Wi-Fi Scanning Configuration / Status Operations

Command opcode Parameters Description

WifiScan 0x0300

WifiType

ChanMask

AcqMode

NbMaxRes

NbScanPerChan

Timeout

AbortOnTimeout

Launches a Wi-Fi passive scanning

WifiGetNbResults 0x0305 --- Get the number of passive scanning results

WifiReadResults 0x0306

Index

NbResults

Format

Return Wi-Fi results

WifiResetCumulTime 0x0307 ---

Initialize cumulative times per phases for

power consumption measurements

WifiReadCumulTime 0x0308 ---

Returns cumulative time per phase for

power consumption measurements
