4.3 Temperature Sensor

A built-in temperature sensor, giving an indication of the internal device temperature, is implemented in the LR1110. The

temperature measurement can be triggered using the command GetTemp( ):

The Temperature value is a function of an internal reference voltage (typ. 1.35V), and a typical temperature characteristic

(typ -1.7mV/°C), and can be approximated using the following formula:

Table 4-6: GetTemp Command

Byte 0 1

Data from Host 0x01 0x1A

Data to Host Stat1 Stat2

Table 4-7: GetTemp Response

Byte 0 1 2

Data from Host 0x00 0x00 0x00

Data to Host Stat1 Temp(15:8) Temp(7:0)

Temperature degC  25

1000

1.7mV/°C–

---------------------------

Temp(10:0)/2047*1.35 - 0.7295 +
