• BitRate defines the (G)FSK bit rate in bits per second. It ranges from 600 b/s up to 300 kb/s with a default value at 4.8
kb/s.
• PulseShape defines the filtering applied to the (G)FSK packet.
• BWF defines the bandwidth
Table 8-18: PulseShape Parameter
PulseShape Description
0x00 No Filter applied
0x08 Gaussian BT 0.3
0x09 Gaussian BT 0.5
0x0A Gaussian BT 0.7
0x0B Gaussian BT 1
Table 8-19: Bandwidth Parameter
BWF Description
0x1F RX_BW_4800 (4.8 kHz DSB)
0x17 RX_BW_5800 (5.8 kHz DSB)
0x0F RX_BW_7300 (7.3 kHz DSB)
0x1E RX_BW_9700 (9.7 kHz DSB)
0x16 RX_BW_11700 (11.7 kHz DSB)
0x0E RX_BW_14600 (14.6 kHz DSB)
0x1D RX_BW_19500 (19.5 kHz DSB)
0x15 RX_BW_23400 (23.4 kHz DSB)
0x0D RX_BW_29300 (29.3 kHz DSB)
0x1C RX_BW_39000 (39 kHz DSB)
0x14 RX_BW_46900 (46.9 kHz DSB)
0x0C RX_BW_58600 (58.6 kHz DSB)
0x1B RX_BW_78200 (78.2 kHz DSB)
0x13 RX_BW_93800 (93.8 kHz DSB)
0x0B RX_BW_117300 (117.3 kHz DSB)
0x1A RX_BW_156200 (156.2 kHz DSB)
0x12 RX_BW_187200 (187.2 kHz DSB)
0x0A RX_BW_234300 (232.3 kHz DSB)
0x19 RX_BW_312000 (312 kHz DSB)
