4.2 RF Switch Control
4.2.1 SetDioAsRfSwitch
DIO5, DIO6, DIO7, DIO8 and DIO10 can be used to control external RF switches or LNAs on the Sub-GHz, GNSS, and Wi-Fi RF
paths using the SetDioAsRfSwitch( ) command:
• RfswEnable value indicates which switch is used (1) and which is not (0). Only the lowest 5 bits of all the configurations
as well as the enable are taken into account. Each Cfg bit corresponds to the state of the RFSW output for that
particular mode:
 Bit 0 - RFSW0 Enabled (DIO5 pin)
 Bit 1 - RFSW1 Enabled (DIO6 pin)
 Bit 2 - RFSW2 Enabled (DIO7 pin)
 Bit 3 - RFSW3 Enabled (DIO8 pin)
 Bit 4 - RFSW4 Enabled (DIO10 pin)
• RfSwStbyCfg value indicates the RFSW DIO states when in standby mode.
• RfSwRxCfg value tells the RFSW DIO states when in RX mode.
• RfSwTxCfg value indicates the RFSW DIO states when in low power TX mode.
• RfSwTxHPCfg value indicates the RFSW DIO states when in high power TX mode.
• RfSwGnssCfg value indicates the RFSW DIO states when in GNSS scanning mode.
• RfSwWifiCfg value indicates the RFSW DIO states when in Wi-Fi scanning mode.
• Byte 7 is RFU
By default, no DIO is used as RF switch: all RFSW outputs are in High-Z state.
This command will only work with the chip in Standby RC mode, otherwise it will return a CMD_FAIL on the next GetStatus
command.
Table 4-5: SetDioAsRfSwitch Command
Byte 0 1 2 3 4 5 6 7 8 9
Data from Host 0x01 0x12
RfSw
Enable
RfSw
StbyCfg
RfSw
RxCfg
RfSw
TxCfg
RfSw
TxHPCfg
RFU
RfSw
GnssCfg
RfSw
WifiCfg
Data to Host Stat1 Stat2
IrqStatus
(31:24)
IrqStatus
(23:16)
IrqStatus
(15:8)
IrqStatus
(7:0)
0x00 0x00 0x00 0x00
