• Data1, Data2, ... , DataN: Provided data, considered as Byte buffers.
• CEStatus: defined in section CEStatus on page 107.
If the 2 MICs are identical, the command will return CRYP_API_SUCCESS, otherwise, CRYP_API_FAIL_CMAC.
12.3.7 CryptoAesEncrypt01
The command CryptoAesEncrypt01( ) encrypts the provided data using the specified Key and return it.
• KeyID: specified Key ID, as defined in Table 12-1: Cryptographic Keys Usage and Derivation. Goes from 0 to 27.
• Data2, ... , DataN: Provided data, considered as Byte buffers.
• CEStatus: defined in section CEStatus on page 107.
• EncryptedData1, EncryptedData2, ... , EncryptedDataN: Encrypted data, considered as Byte buffers
12.3.8 CryptoAesEncrypt
The command CryptoAesEncrypt( ) encrypts the provided data using the specified Key and return it.
Table 12-14: CryptoAesEncrypt01 Command
Byte 0 1 2 3 4 … N+2
Data from
Host
0x05 0x07 KeyID (7:0) 0x01 Data2 … DataN
Data to Host Stat1 Stat2
IrqStatus
(31:24)
IrqStatus
(23:16)
IrqStatus
(15:8)
… 0x00
Table 12-15: CryptoAesEncrypt01 Response
Byte 0 1 2 … N+1
Data from Host 0x00 0x00 0x00 … 0x00
Data to Host Stat1 CEStatus
Encrypted
Data1
…
Encrypted
DataN
Table 12-16: CryptoAesEncrypt Command
Byte 0 1 2 3 … N+2
Data from Host 0x05 0x08 KeyID (7:0) Data1 … DataN
Data to Host Stat1 Stat2
IrqStatus
(31:24)
IrqStatus
(23:16)
… 0x00
