Wi-Fi g

BPSK 1/2 6

4 BPSK 3/4 9

5 QPSK 1/2 12

6 QPSK 3/4 18

7 16-QAM 1/2 24

8 16-QAM 3/4 36

Wi-Fi n

mixed

mode

BPSK 1/2 6.5

12 QPSK 1/2 13

13 QPSK 3/4 19.5

14 16-QAM 1/2 26

15 16-QAM 3/4 39

19 BPSK 1/2 7.2

20 QPSK 1/2 14.4

21 QPSK 3/4 21.7

22 16-QAM 1/2 28.9

23 16-QAM 3/4 43.3

Table 10-5: Wi-Fi Channel ID Field

Channel ID 1 2 3 4 5 6 7 8 9 10 11 12 13 14

Center Freq

(MHz)

2412 2417 2422 2427 2432 2437 2442 2447 2452 2457 2462 2467 2472 2484

Table 10-6: Wi-Fi MacValidation Field

MacValidation Value Meaning

1 MAC Address from a gateway

2 MAC Address from a phone

3 Undetermined

Table 10-7: Wi-Fi Frame Control Field

Bit (0:1) (2:5) 6 7

Fields Type SubType ToDS FromDS

Table 10-4: Wi-Fi DatarateID Field

DatarateID Signal type Modulation Coding rate Datarate (Mbps)
