11.4.4 GnssGetNbSvDetected

The command GnssGetNbSvDetected( ) allows to retrieve the number of Satellites Vehicles detected during the last GNSS

Scanning.

11.4.5 GnssGetSvDetected

The command GnssGetSvDetected( ) allows to retrieve the ID and the C/N0 of the Satellites Vehicles detected during the last

GNSS Scanning.

Table 11-10: GnssGetNbSvDetected Command

Byte 0 1

Data from Host 0x04 0x17

Data to Host Stat1 Stat2

Table 11-11: GnssGetNbSvDetected Response

Byte 0 1

Data from Host 0x00 0x00

Data to Host Stat1 NbSv

Table 11-12: GnssGetSvDetected Command

Byte 0 1

Data from Host 0x04 0x18

Data to Host Stat1 Stat2

Table 11-13: GnssGetSvDetected Response

Byte 0 1 2 3 ...

Data from Host 0x00 0x00 0x00 0x00 ...

Data to Host Stat1 SvId1 C/N0 SvId2 ...
