4.1.2.2 SetDioIrqParams
The command SetDioIrqParams( ) configures which interrupt signal should be activated on the DIO9 and/or DIO11 interrupt
pin (referred to as IRQ pin 1 and/or 2).
4.1.2.3 ClearIrq
The ClearIrq( ) command clears the selected interrupt signals by writing a 1 in the respective bit.
The IrqToClear is identical to IrqToEnable assignment.
Table 4-3: SetDioIrqParams Command
Byte 0 1 2 3 4 5
Data from Host 0x01 0x13
Irq1ToEnable
(31:24)
Irq1ToEnable
(23:16)
Irq1ToEnable
(15:8)
Irq1ToEnable
(7:0)
Data to Host Stat1 Stat2
IrqStatus
(31:24)
IrqStatus
(23:16)
IrqStatus
(15:8)
IrqStatus
(7:0)
Byte 6 7 8 9
Data from Host
Irq2ToEnable
(31:24)
Irq2ToEnable
(23:16)
Irq2ToEnable
(15:8)
Irq2ToEnable
(7:0)
Data to Host 0x00 0x00 0x00 0x00
Table 4-4: ClearIrq Command
Byte 0 1 2 3 4 5
Data from Host 0x01 0x14
IrqToClear
(31:24)
IrqToClear
(23:16)
IrqToClear
(15:8)
IrqToClear
(7:0)
Data to Host Stat1 Stat2
IrqStatus
(31:24)
IrqStatus
(23:16)
IrqStatus
(15:8)
IrqStatus
(7:0)
