10.3.2 Basic Result Format
The Basic Result structure is organized as continuous series of MAC Addresses Basic Results, each MAC Address Basic Result
being coded on 9 Bytes, defined in Table 10-2: Basic Results Format per MAC Address here below. The maximum number
of MAC Addresses reported is 32.
• Wi-Fi Type: coded on 8 bits:
bits 0-1: Wi-Fi signal type:
1: Wi-Fi b
2: Wi-Fi g
3: Wi-Fi n
bits 2-7: DatarateID, coded as indicated inTable 10-4: Wi-Fi DatarateID Field.
• Channel info: coded on 8 bits:
bits 0-3: ChannelID, coded as indicated in Table 10-5: Wi-Fi Channel ID Field. ChannelID indicates the Wi-Fi channels
configured for the scan.
bits 4-7: MacValidation, coded as indicated inTable 10-6: Wi-Fi MacValidation Field.
MacValidation indicates if the MAC address belongs to a gateway, to a phone or if it is undetermined because MAC address
is extracted from a packet.
• RSSI: RSSI value of the signal captured, coded on 8 bits
• MAC: MAC address of the Access Point, coded on 6 bytes:
MAC6:MAC5:MAC4:MAC3:MAC2:MAC1, from MSB to LSB
10.3.3 Full Result Format
• The Full Result structure is organized as continuous series of MAC Addresses Full Results, each MAC Address Full Result
being coded on 22 Bytes, defined in Table 10-3: Full Results Format per MAC Address here below. The maximum
number of MAC Addresses reported is 32.
Table 10-2: Basic Results Format per MAC Address
Byte 0 1 2 3 4 5 6 7 8
Content Wi-Fi type Channel
info
RSSI MAC6 MAC5 MAC4 MAC3 MAC2 MAC1
