15.3 Radio Configuration / Status Operations
Table 15-3: Radio Configuration / Status Operation
Command Opcode Parameters Description
ResetStats 0x0200 --- Resets RX statistics
GetStats 0x0201 --- Gets RX statistics
GetPacketType 0x0202 --- Gets current radio protocol
GetRxBufferStatus 0x0203 --- Gets RS buffer status
GetPacketStatus 0x0204 --- Gets RX packet status
GetRssiInst 0x0205 --- Gets instantaneous RSSI
SetGfskSyncWord 0x0206 Syncword
Set the 64 bit
(G)FSK syncword
SetLoRaPublicNetwork 0x0208 PublicNetwork
Changes LoRa® sync work for private or
public network
SetRx 0x0209 Timeout(23:0) Set chip into RX mode
SetTx 0x020A Timeout(23:0) Set chip into TX mode
SetRfFrequency 0x020B RfFreq (31:0) Set PLL frequency
AutoTxRx 0x020C
Delay(23:0)
IntermediaryMode(7:0)
Timeout2(23:0)
Activate or deactivates the auto TX auto RX
mode
SetCadParams 0x020D
SymbolNum(7:0)
DetPeak(7:0)
DetMin(7:0)
PeakSumEn
ExitMode(7:0)
Timeout(23:0)
Configure LoRa® CAD mode
SetPacketType 0x020E PacketType
Define radio protocol (
(G)FSK, LoRa®)
SetModulationParam 0x020F Params[7..0] Configure modulation parameters
SetPacketParam 0x0210 Params[8..0] Configure packet parameters
SetTxParams 0x0211
Power
RampTime
Set TX power and ramp time
SetPacketAdrs 0x0212
NodeAddr
BroadcastAddr
Set the Node address and the broadcast
address for the
(G)FSK packets
SetRxTxFallbackMode 0x0213 Fall-back mode
Defines into which mode the chip goes after
a TX / RX done.
SetRxDutyCycle 0x0214
RxPeriod(23:0)
SleepPeriod(23:0)
Start RX Duty Cycle mode
