AppEUI is coded on 8 Bytes, in little endian.

13.2.3 ReadDevicePin

The command ReadDevicePin( ) allows reading back the LR1110 PIN unique number for the LoRa Cloud™ Device Join

service.

PIN is coded on 4Bytes, in little endian.

Table 13-3: GetAppEUI Command

Byte 0 1

Data from Host 0x01 0x25

Data to Host Stat1 Stat2

Table 13-4: GetAppEUI Response

Byte 0 1 ... 8

Data from

Host

0x00 0x00 ... 0x00

Data to

Host

Stat1

AppEUI

(63:56)

...

AppEUI

(7:0)

Table 13-5: ReadDevicePin Command

Byte 0 1

Data from Host 0x01 0x25

Data to Host Stat1 Stat2

Table 13-6: ReadDevicePin Response

Byte 0 1 2 3 4

Data from

Host

0x00 0x00 0x00 0x00 0x00

Data to

Host

Stat1

(31:24)

(23:16)

(15:8)

(7:0)
