2.6 Modes Transitions & Timings

Table 2-12: Mode Transitions lists the main modes transitions of the LR1110. Please refer to Figure 2-1: LR1110 Modes and

Transitions for a representation of the LR1110 modes and modes transitions:

Table 2-12: Mode Transitions

Transition

Mode Typical value (s)

POR to STBY_RC 180e3

SLEEP to STBY_RC (no data retention) 30e3

SLEEP to STBY_RC (with data retention) <1000

STBY_RC to STBY_XOSC 43

STBY_XOSC to FS 50

STBY_XOSC to TX 105

FS to RX (LoRa,

(G)FSK)

FS to TX 102

RX to FS 11

RX to TX 107
