LR1110

User Manual Rev.1.0

UM.LR1110.W.APP March 2020

49 of 130

Semtech

www.semtech.com

7.2.12 SetRxBoosted

The command SetRxBoosted( ) sets the device in RX Boosted mode, allowing a ~2 dB increased sensitivity, at the expense of

a ~2 mA higher current consumption in RX mode.

• RxBoosted: Activates the Rx Boosted mode.

RxBoosted=0: RX Boosted mode deactivated

RxBoosted=1: RX Boosted mode activated

Other values are RFU

Table 7-15: SetRxBoosted Command

Byte 0 1 2

Data from Host 0x02 0x27 RxBoosted

Data to Host Stat1 Stat2 IrqStatus (31:24)
