ErrorStat contains all the possible error flags that could occur during different chip operations:
• bit 0: LF_RC_CALIB_ERR. Calibration of the low frequency RC has not been done. To fix it try redoing a calibration.
• bit 1: HF_RC_CALIB_ERR. Calibration of the high frequency RC has not been done. To fix it try redoing a calibration.
• bit 2: ADC_CALIB_ERR. Calibration of the ADC has not been done. To fix it try redoing a calibration.
• bit 3: PLL_CALIB_ERR. Calibration of the maximum and minimum frequencies was not done. To fix it redo the PLL
calibration.
• bit 4: IMG_CALIB_ERR. Calibration of the image rejection was not done. To fix it redo the image calibration.
• bit 5: HF_XOSC_START_ERR. High frequency XOSC did not start correctly. To fix it redo a reset, or send SetTcxoCmd() if
a TCXO is connected and re do calibrations
• bit 6: LF_XOSC_START_ERR. Low frequency XOSC did not start correctly. To fix it redo a reset.
• bit 7: PLL_LOCK_ERR. The PLL did not lock. This can come from too high or too low frequency configuration, or if the
PLL was not calibrated. To fix it redo a PLL calibration, or use other frequencies.
• bit 8: RX_ADC_OFFSET_ERR. Calibration of the ADC offset could not been done. To fix it redo a calibration.
• bit 9-15: RFU.
3.5.2 ClearErrors
The command ClearErrors( ) clears all errors flags pending in the device. The error flags cannot be cleared individually.
Table 3-3: GetErrors Command
Byte 0 1
Data from Host 0x01 0x0D
Data to Host Stat1 Stat2
Table 3-4: GetErrors Response
Byte 0 1 2
Data from Host 0x00 0x00 0x00
Data to Host Stat1 ErrorStat(15:8) ErrorStat(7:0)
Table 3-5: ClearErrors Command
Byte 0 1
Data from Host 0x01 0x0E
Data to Host Stat1 Stat2
