POR Power On Reset

PSDU Wi-Fi PLCP Service Data Unit

RC13M 13 MHz Resistance-Capacitance Oscillator

RC64k 64 kHz Resistance-Capacitance Oscillator

RFO Radio Frequency Output

RFU Reserved for Future Use

RTC Real-Time Clock

SCK Serial Clock

SF Spreading Factor

SN Sequence Number

SNR Signal to Noise Ratio

SPI Serial Peripheral Interface

SSB Single Side Bandwidth

STA Wi-Fi Client Station

STDBY Standby

TCXO Temperature-Compensated Crystal Oscillator

XOSC Crystal Oscillator
