Accessories

Line/instrument cables

The following cables are available to connect instruments and line sources

to the SK 300 G4 and SK 500 G4 bodypack transmitters:

• Sennheiser CL 2

Line cable with XLR-3F plug on lockable 3.5 mm jack plug, article no.

004840

►

• Sennheiser Ci 1-N

Guitar cable with 6.3 mm jack plug on lockable 3.5 mm jack plug, article

no. 005021

►
