Using the EM 300-500 G4
86
9 Output gain
• Current output gain of the audio frequency signal at the 6.3 mm sock-
et / XLR socket
• See “AF Out menu item”
10Equalizer setting
• Current equalizer setting
• See “Equalizer menu item”
11MUTE muting function
• Receiver or transmitter is muted
• See “Muting the audio output”
12Battery status of the transmitter
• SKM 300 G4: see “Inserting and removing the batteries/recharge-
able batteries”
• SKM 500 G4: see “Inserting and removing the batteries/recharge-
able batteries”
• SK 300 G4: see “Inserting and removing the batteries/rechargeable
batteries”
• SK 500 G4: see “Inserting and removing the batteries/rechargeable
batteries”
13Transmitter type
• Product name of the connected transmitter
Transmitter Parameters standard display
The Transmitter Parameters standard display shows the microphone mod-
ule (only for SKM) and the transmitter type.
►
