36 | TeamConnect
The Configuration Manager software
Status Indicators
The status indicators on the bottom of the window indicate the following
information.
Status Indicator Status
Communications Indicates if an SL TeamConnect CU1 is connected via USB,
RS-232 or Ethernet or not connected.
Telephone In Use Indicates if the telephone line is in use.
Mic / Mute Gating Indicates if a microphone channel is muted or gated.
Menu Bar
The menu bar provides access to the following menus and settings:
File menu
Option Settings
New File Creates a new configuration settings file (file extension:
.CU1).
This option opens a new configuration screen. An
SL TeamConnect CU1 does not need to be connected. The
settings can be configured working offline and can be
imported to a connected SL TeamConnect CU1 later.
Open File Opens an existing configuration settings file (.CU1).
Save File Saves the current configuration settings as a configuration
settings file (.CU1) on your computer.
Save File As Saves the current configuration settings as a new
configuration settings file (.CU1) on your computer.
Import File Imports a configuration settings file to the currently
connected SL TeamConnect CU1.
Use this option if the configuration settings have been
configured offline and are intended to be applied to a
connected SL TeamConnect CU1.
Exit
Configuration Preset menu
This menu is only available in the menu bar when a configuration screen is
open.
Option Settings
Save Current
Configuration As
Preset
Saves the current configuration settings in one of the four
preset slots.
This menu is only available when a configuration screen is
open.
For more information on using the presets refer to
chapter “Using presets” on page 53.
