46 | TeamConnect
The Configuration Manager software
Configuring the settings of the SL TeamConnect CB1
The settings of the USB and Headset ports of the SL TeamConnect CB1 are
configured in the COM Settings area of the configuration screen.
To configure the settings of the SL TeamConnect CB1:
X Click on the COM Settings icon in the configuration screen.
The COM Settings configuration window opens.
The COM Settings configuration window has two tabs where you can adjust
the following settings:
Tab Option Settings
Level USB Tx / USB Rx Adjusts transmit and receive levels of
the USB port.
Headset Tx /
Headset Rx
Adjusts transmit and receive levels of
the headset port.
Mute Mutes the selected channel.
NOM Activates the NOM function (Number
of Open Mics).
NOM maintains a constant output level
by automatically adjusting gain levels
based on the number of microphones
gated on and routed to the selected
output channel. NOM reduces the
output level proportionally by 3 dB for
every doubling in the number of open
microphones.
ALC Activates auto level control, which
maintains a consistent level on the
Headset Rx channel.
LEC Activates line echo cancellation.
NLP Activates non-linear processing.
Configuration Headset
Configuration
Adjusts headset gain and pin
allocation settings.
X Open the respective tab to adjust the desired settings.
