TeamConnect | 45
The Configuration Manager software
Tab Option Settings
Level Receive ALC Activates auto level control, which
keeps the telephone audio level
consistent with audio levels coming
from other sources.
Telco Receive Adjusts the incoming telephone audio
signal.
ClearEffect Activates the ClearEffect.
Telephone lines limit audio bandwidth
to a range of 300 Hz to 3.3 kHz. The
ClearEffect enhances the incoming
signal from a telephone line to emulate
wideband audio by adding high and
low frequencies to the audio signal.
Telco Transmit Adjusts the outgoing telephone audio
signal.
NOM Activates the NOM function (Number
of Open Mics).
NOM maintains a constant output level
by automatically adjusting gain levels
based on the number of microphones
gated on and routed to the selected
output channel. NOM reduces the
output level proportionally by 3 dB for
every doubling in the number of open
microphones.
Dialer Country Setting Selects the region you are using the
TeamConnect system in.
If the SL TeamConnect CU1 is connected
to the analog landline network:
X Select your region
If the SL TeamConnect CU1 is connected
to a PBX telephone system:
X Select the region “US/Canada”
Flash Setting Adjusts the appropriate flash value
for the local telephone network or the
telephone system (PBX).
Volume
Assignment
Defines which channel is controlled
with the volume slider in the dialer. If
you want to control several channels
you can patch them to a processing
channel in the Mixer Console and
indicate this processing channel here.
Set Volume Sets the volume of the selected
channel.
Global Mic Mutes all microphones. The
previous mute settings of the single
microphones will be overwritten.
X Open the respective tab to adjust the desired settings.
