40 | TeamConnect
The Configuration Manager software
Gating tab
Option Settings
Max Number of
Microphones
Defines the maximum number of microphones which are
active simultaneously.
Gate Mode • Auto (default): Gating depends on the maximum
number of microphones.
• Man On: Gates the channel on. The audio signal is on
permanently. The channel is counted in the maximum
number of microphones.
• Man Off: Gates the channel off. The audio signal is
attenuated by the specified Off Attn level.
• Override On: Gates the channel on. The audio signal
is on permanently. This channel is not counted in the
maximum number of microphones. That means this
microphone is always active.
• PA Adaptive: The audio level of the output specified
under System Settings in the Processing tab (see
Processing tab above) is used as the reference
ambient audio level at which the mic is not gated on.
Gate Ratio Defines how much louder the audio level of the
microphone must be compared to the ambient audio
level before the channel automatically gates on if Auto
is selected. The default value is 15 dB.
Hold Time Defines how long the channel stays gated on after the
audio level falls below the specified Gate Ratio. The
default value is 0.3 seconds.
Off Attn Defines the attenuation of the audio signal when the
channel is gated off. The default value is 12 dB.
Decay Rate Defines how fast the audio signal is turned off after the
specified Hold Time. The default value is Medium.
Chairman
Override
Activates gating priority of the selected mic over any
other mic. When a mic with Chairman Override enabled
gates on, all mics which do not have Chairman Override
enabled will gate off.
AEC Meter tab (Acoustic Echo Cancellation)
Option Settings
Echo Return
Loss (ERL)
Shows the difference between the reference signal level
and the input level to the echo canceller.
Echo
Return Loss
Enhancement
(ERLE)
Shows the difference of the loss through the echo
cancellation and the non-linear processing chain
Total Echo Shows the total ERL and ERLE reduction.
X Open the respective tab to adjust the desired settings.
