外装部 2(Exteriors 2)
NO.
PARTS CODE
Inter-
change
PRICE RANK
NEW
MARK
PART
RANK
DESCRIPTION
TR No.
Effective
time
Ex. Ja.
1
GCAB-0 042 QSTF AP EQ D
Rear cabinet left (Except Japan) 後ｷｬﾋﾞ左
GCAB-0 042 QSTG AP EQ D
Rear cabinet left (Japan) 後ｷｬﾋﾞ左
3 XHB S73 0P0800 0 AB DD C
Screw(3×8) ﾋﾞｽ
4 GCA B-0 145QSZ Z AU EZ C
Delivery tray cabinet rear 排紙ﾄﾚｲｷｬﾋﾞ後
5 GCO V-0 056QST 1 AG DS D
Rear cabinet maintenance cover 後ｷｬﾋﾞ
ﾒﾝﾃﾅﾝｽｶﾊﾞｰ
6
GCAB-0 043 QSTC AM EG D
Rear cabinet lower (100V Series) 後ｷｬﾋﾞ下
GCAB-0 152 QSZZ AM EG D
Rear cabinet lower (200V Series) 後ｷｬﾋﾞ下
7 XEB S74 0P1000 0 AA DD C
Screw(4×10) ﾋﾞｽ
8
GCAB-0 085 QST5 AY FQ D
Rear cabinet right (Except Japan) 後ｷｬﾋﾞ右
GCAB-0 085 QST6 1AYFG D
Rear cabinet right (Except Japan) 後ｷｬﾋﾞ右
09/10 R/C
GCAB-0 085 QST6 AY FG D
Rear cabinet right (Japan) 後ｷｬﾋﾞ右
9 GCO V-0 034QST C AK DX C
Rear cabinet memory cover 後ｷｬﾋﾞﾒﾓﾘｰｶﾊﾞｰ
10 PCO VP0130 QSZZ AM EG D
Delivery dummy cover (Except Japan) 排紙ﾀﾞﾐｰｶﾊﾞｰ
11 MSP RD0189 QSZZ AB DJ C
Right cabinet spring 右ｷｬﾋﾞｽﾌﾟﾘﾝｸﾞ
12 MLE VP0069 QSTZ -ADDJ C
Right cabinet lever [Missing parts code] 右ｷｬﾋﾞﾚﾊﾞｰ
1st lot
13 GDO R-0003 QST7 -APEQ D
Right cabinet door [Missing parts code] 右ｷｬﾋﾞﾄﾞｱ
1st lot
14 NRO LP1060 FCZZ AF DS C
U-turn roller U ﾀｰﾝﾛｰﾗｰ
15 MSP RT0229 GCAZ AC DJ C
FU spring R FU ｽﾌﾟﾘﾝｸﾞ R
16 GCA B-0039 QSTC -ASEZ D
Right cabinet [Missing parts code] 右ｷｬﾋﾞ
1st lot
17 GCO V-0043 QST2 AX FG D
Option PWB cover ｵﾌﾟｼｮﾝ基板ｶﾊﾞｰ
18 PFI LZ0016 QSZZ AS EQ B
Ozone filter ｵｿﾞﾝﾌｨﾙﾀｰ
19 GCO V-0086 QSZZ AN EG C
Delivery cover 排紙ｶﾊﾞｰ
21
GCAB-0 149 QSZZ AV FG C
Left cabinet (Japan) 左ｷｬﾋﾞ
GCAB-0 149 QSZ1 -AVFG C
Left cabinet [Missing parts code](Except Japan) 左ｷｬﾋﾞ
1st lot
23 GCA B-0142 QSZZ AL EB C
Front cabinet right 前ｷｬﾋﾞ右
24
GCAB-0 148 QSZZ AW FG C
Right cabinet front 右ｷｬﾋﾞ前
GCAB-0 148 QSZ1 3AWFG C
Right cabinet front [Improve reliability] 右ｷｬﾋﾞ前
09/08 Mid
25 LBN DZ0007 QSZZ AC DJ C
Front cabinet band A2R 前ｷｬﾋﾞ
ﾊﾞﾝﾄﾞ A2R
26 GCA B-0141 QSZZ AT EZ C
Front cabinet 前ｷｬﾋﾞ
27 TLA BZ5148 FCZZ AC DJ D
Energy star label [MX-M260(Except Argentina)
/M260FG/M260FP/M310(Except Argentina)
/M310FG/M310FP,AR-5726/5731(East Europe)] ｴﾅｼﾞｰｽﾀｰﾗﾍﾞﾙ
37 LX- BZ0082 QSPZ AA DD C
Screw(3×8) ﾋﾞｽ
39 TCA UA1069 FCZZ AC DJ D
Service caution label (Except Japan) ｻｰﾋﾞｽ注意ﾗﾍﾞﾙ
40
TLABZ0 793 QSZZ AC DJ D
Class 1 label NEW (Except North America,Japan) ｸﾗｽ 1 ﾗﾍﾞﾙ NEW
TLABG5 005 FCZZ AC DJ D
Class 1 label JPN (Japan) ｸﾗｽ 1 ﾗﾍﾞﾙ JPN
44 TLA BH0483 QSZZ AC DJ D
Warm heater label (Japan) 保温ﾋｰﾀｰﾗﾍﾞﾙ
49 MAR MP0050 QSZZ AF DS D
Paper fixing arm 用紙押えｱｰﾑ
50 GCO VH0024 QST2 AE DS D
FAX connector cover (Japan) FAX ｺﾈｸﾀｶﾊﾞｰ
52 TLA BH5200 FCZZ AB DJ D
Plug caution label (Japan) ﾌﾟﾗｸﾞｺｰｼｮﾝ J
53 TCA UH1071 FCZZ BC GD D
Service caution label PO ｻｰﾋﾞｽ注意ﾗﾍﾞﾙ
(Germany,Switzerland,East Europe) PO
54 TLA BZ5048 FCZZ AB DJ D
WEEE mark label [Germany,Switzerland,East Europe,
Europe,U.kingdom,AR-5726/5731] WEEE ﾏｰｸﾗﾍﾞﾙ
61
PSHEZ0 568 QSZZ AD DJ C
R cabinet sheet 右ｷｬﾋﾞｼｰﾄ
PSHEZ0 568 QSZZ -ADDJ C
R cabinet sheet 右ｷｬﾋﾞｼｰﾄ
09/11
63 PCO VP0142 QSZZ AE DS C
Fan cover ﾌｧﾝｶﾊﾞｰ
65 GCA B-0144 QSZZ AK DX C
Delivery tray joint cabinet 排紙ﾄﾚｲ
連結ｷｬﾋﾞ
66 PCO VP0144 QSZZ AD DJ C
R cabinet lever cover (Except Japan) 右ｷｬﾋﾞﾚﾊﾞｰｶﾊﾞｰ
67 HBD GD0058 FCZZ AT EQ C
Front cabinet badge [MX-M Series] 前ｷｬﾋﾞﾊﾞｯｼﾞ
68
CBDGD0 062 FC35 AH DX C
Model name plate [MX-M260] 機種名ﾌﾟﾚｰﾄ
CBDGD0 062 FC34 AH DX C
Model name plate [MX-M310] 機種名ﾌﾟﾚｰﾄ
CBDGD0 062 FC39 AG DX C
Model name plate [MX-M260N] 機種名ﾌﾟﾚｰﾄ
CBDGD0 062 FC38 AG DX C
Model name plate [MX-M310N] 機種名ﾌﾟﾚｰﾄ
CBDGD0 062 FC42 AG DX C
Model name plate [MX-M260FP] 機種名ﾌﾟﾚｰﾄ
CBDGD0 062 FC40 AG DX C
Model name plate [MX-M310FP] 機種名ﾌﾟﾚｰﾄ
CBDGD0 062 FC43 AG DX C
Model name plate [MX-M260FG] 機種名ﾌﾟﾚｰﾄ
CBDGD0 062 FC41 AG DX C
Model name plate [MX-M310FG] 機種名ﾌﾟﾚｰﾄ
CBDGD0 004 QS01 AN EQ C
Model name plate [AR-5726] 機種名ﾌﾟﾚｰﾄ
CBDGD0 004 QS02 AN EQ C
Model name plate [AR-5731] 機種名ﾌﾟﾚｰﾄ
69 PBO X-0006 QSZ1 AE DS D
Delivery sensor BOX 排紙ｾﾝｻｰﾎﾞｯｸｽ
70 XEB S730P1 0000 AC DD C
Screw(3×10) ﾋﾞｽ
71 VHP GP1S73 P+-18 AF DS B
Photo sensor(GP1S73P) ﾌｫﾄｾﾝｻｰ
72 MLE VP0068 QSTZ AC DJ C
Delivery tray actuator 排紙ﾄﾚｲ
ｱｸﾁｭｴｰﾀｰ
73 DHA I-0370 QSPZ AF DS C
Delivery paper detect sensor harness 排紙紙検知ｾﾝｻｰ
ﾊｰﾈｽ
74 GCA B-0143 QSZZ BA FX D
Delivery tray cabinet 排紙ﾄﾚｲｷｬﾋﾞ
75 PSH EZ0392 QSZ1 AB DJ C
Paper feed solenoid sound proof B 給紙ｿﾚﾉｲﾄﾞ
消音材 B
79 TLA BZ5059 FCZZ AB DJ D
BM link label [MX-M260FP/M310FP] BM ﾘﾝｸﾗﾍﾞﾙ
