Sharp AR-5726 - W 2 Nd 搬送部 (2 Nd Paper Transfer Section)

– 53 –
Update : 2009/11/16
W
2nd 搬送部 (2nd paper transfer section)
NO.
PARTS CODE
Inter-
change
PRICE RANK
NEW
MARK
PART
RANK
DESCRIPTION
TR No.
Effective
time
Ex. Ja.
1 MSP RC0 378QSZ 1 AB DJ C
Lock spring ﾛｯｸｽﾌﾟﾘﾝｸﾞ
2 MLO KZ0 001QSZ Z AC DJ C
Paper guide lock ﾍﾟｰﾊﾟｰｶﾞｲﾄﾞﾛｯｸ
3 XEP S73 0P08X0 0 AA DD C
Screw(3×8X) ﾋﾞｽ
4 PGI DM0 068QSZ 1 AP EG C
Transport paper guide 搬送
ﾍﾟｰﾊﾟｰｶﾞｲﾄﾞ
5 MAR MP0 015QSZ Z AD DJ C
2nd door arm 2nd ﾄﾞｱｱｰﾑ
6 NSF TZ0 054QSZ 1 AD DJ C
Transport paper guide shaft 搬送
ﾍﾟｰﾊﾟｰｶﾞｲﾄﾞ
ｼｬﾌﾄ
7 NRO LP1 060FCZ Z AF DS C
U-turn roller U ﾀｰﾝﾛｰﾗｰ
8 MSP RP0 345QSZ 1 AD DJ C
Transport paper guide spring 搬送
ﾍﾟｰﾊﾟｰｶﾞｲﾄﾞ
ｽﾌﾟﾘﾝｸﾞ
9 XEB S73 0P0800 0 AC DD C
Screw(3×8) ﾋﾞｽ
10 GCO VA0026 QSTC -APEQ D
Right cover [Missing parts code] 右ｶﾊﾞｰ
1st lot
11 XEB S730P1 0000 AC DD C
Screw(3×10) ﾋﾞｽ
12 PCO VP0089 QSZZ AD DJ D
Plate cover ﾌﾟﾚｰﾄｶﾊﾞｰ
13 LPL TP0409 QSZZ AC DJ C
Separator plate AND2 捌きﾌﾟﾚｰﾄAND2
14 PSH EZ0515 QSZZ AG DX A
Separator sheet 捌きｼｰﾄ
15 NRO LR0130 QSZZ AL EB C
Transport roller 搬送ﾛｰﾗｰ
16 MSP RC0270 QSZZ AB DJ C
Separator plate spring 捌きﾌﾟﾚｰﾄ
ｽﾌﾟﾘﾝｸﾞ
17 NBR GZ0503 FCZZ AC DJ C
Bearing 軸受
18 LST PP0011 QSZZ AC DJ C
Resin E type ring 樹脂 E ﾘﾝｸﾞ
19 LRA LP0009 QSZ2 AP EQ C
Cassette rail R ｶｾﾂﾄﾚｰﾙ R
20 XBP S730P0 8KS0 AB DD C
Screw(3×8KS) ﾋﾞｽ
21 NKO M-0005 QSZZ AC DJ C
Cassette guide collar ｶｾｯﾄｶﾞｲﾄﾞｺﾛ
22 NSF TZ0048 QSPZ AF DS C
Cassette collar shaft ｶｾｯﾄｺﾛ軸
23 PGI DM0074 QSZZ AK DX C
2nd U-turn guide 2ndU ﾀｰﾝｶﾞｲﾄﾞ
24 XEB S740P1 2000 AA DD C
Screw(4×12) ﾋﾞｽ
25 PSH EZ0301 QSZZ AC DJ C
Rail R side sheet F ﾚｰﾙ R ｻｲﾄﾞｼｰﾄ F
26 PSH EZ0302 QSZZ AC DJ C
Rail R side sheet R ﾚｰﾙ R ｻｲﾄﾞｼｰﾄ R
27 MSP RD0287 QSZZ AC DJ C
Paper feed sub roller spring 給紙補助ﾛｰﾗｰ
ｽﾌﾟﾘﾝｸﾞ
28 NRO LP0087 QSZZ AD DJ C
Paper feed sub roller 給紙補助ﾛｰﾗｰ
29 NSF TZ0101 QSZZ AC DJ C
Paper feed sub roller shaft 給紙補助ﾛｰﾗｰ軸
30 PSH EZ0356 QSZ1 AE DS C
Plate cover sheet ﾌﾟﾚｰﾄｶﾊﾞｰｼｰﾄ
31 PSH EZ0347 QSZ1 AC DJ C
2nd rail R sheet 2nd ﾚｰﾙ R ｼｰﾄ
33 LPL TM0396 QSZ1 AD DJ C
Separator guide plate 捌きｶﾞｲﾄﾌﾟﾚｰﾄ
34 PSP AZ0055 QSZZ AA DJ C
Plate cover spacer ﾌﾟﾚｰﾄｶﾊﾞｰ
ｽﾍﾟｰｻｰ
35 LX- WZ0064 FCZZ AA DD C
Push nut(M3) ﾌﾟｯｼｭﾅｯﾄ
501 CCO VP0089 RS5 5 -APEQ E
Plate cover unit [Missing parts code] ﾌﾟﾚｰﾄｶﾊﾞｰﾕﾆｯﾄ
1st lot
502 CGI DM0068 RS5 5 -AUEZ E
Transport paper guide unit [Missing parts code] 搬送
ﾍﾟｰﾊﾟｰｶﾞｲﾄﾞ
ﾕﾆｯﾄ
1st lot
503 CPL TP0409 RS5 1 AN EG E
Separation plate unit 分離ﾌﾟﾚｰﾄﾕﾆｯﾄ
53
