Sharp AR-5726 - G 搬送部 (Paper Transfer Section)

– 21 –
Update : 2009/11/16
G
搬送部 (Paper transfer section)
NO.
PARTS CODE
Inter-
change
PRICE RANK
NEW
MARK
PART
RANK
DESCRIPTION
TR No.
Effective
time
Ex. Ja.
1 XEB S74 0P1200 0 AA DD C
Screw(4×12) ﾋﾞｽ
2 PCO VP0 053QSZ 6 AK EB D
Middle frame cover 中間ﾌﾚｰﾑｶﾊﾞｰ
3 MSP RD0 194QSZ 1 AD DJ C
PS earth spring LP PS ｱｰｽ
ｽﾌﾟﾘﾝｸﾞ LP
4 MSP RC0 291QSZ Z AC DJ C
PS pressure spring PS 加圧ｽﾌﾟﾘﾝｸﾞ
5 NSF TZ0 065QSZ 1 AD DJ C
PS sub shaft PS 従動軸
6 NKO M-0 006QSZ Z AC DJ C
PS collar(φ13.5) PS ｺﾛ
7 PSH EZ0 133QSZ Z AD DJ C
Paper feed sheet 給紙用ｼｰﾄ
8 XEB S74 0P1000 0 AA DD C
Screw(4×10) ﾋﾞｽ
9 PGI DM0 067QST 1 AP EQ C
Base plate paper feed guide 台板給紙ｶﾞｲﾄﾞ
10 MSP RD0233 QSZ1 AC DJ C
MF actuator spring MF ｱｸﾁｭｴｰﾀｰ
ｽﾌﾟﾘﾝｸﾞ
11 MLE VP0023 QSZZ AE DS C
MF actuator MF ｱｸﾁｭｴｰﾀｰ
12 MLE VP0044 QSZZ AE DS C
MF actuator 2 MF ｱｸﾁｭｴｰﾀｰ 2
13 LPL TP0348 QSZZ AC DJ C
Separator plate 捌きﾌﾟﾚｰﾄ
14 MSP RC0301 QSZZ AD DJ C
Pressure plate spring 圧着板ｽﾌﾟﾘﾝｸﾞ
15 PFT A-0019 QSZZ AE DS D
Pressure plate cover 圧着板蓋
16 XEB S730P1 0000 AC DD C
Screw(3×10) ﾋﾞｽ
17 PSH EZ0242 QSZ1 AH DX C
Pressure plate sheet 圧着板ｼｰﾄ
18 LRA LP0008 QSZ2 AN EG C
Base plate rail R 台板ﾚｰﾙ R
19 VHP GP1S73 P+-18 AF DS B
Photo sensor(GP1S73P) ﾌｫﾄｾﾝｻｰ
20 DHA I-0398 QSPZ AE DS C
Manual paper feed P-IN harness 手差し P-INﾊｰﾈｽ
21 MSP RD0202 QSZZ AB DJ C
Manual paper feed P-IN actuator spring 手差し P-IN
ｱｸﾁｭｴｰﾀｰ
ｽﾌﾟﾘﾝｸﾞ
22 MLE VP0057 QSZZ AC DJ C
Manual paper feed P-IN actuator 手差し P-IN
ｱｸﾁｭｴｰﾀｰ
23 PSH EZ0515 QSZZ AG DX A
Separator sheet 捌きｼｰﾄ
24 LPL TP0409 QSZZ AC DJ C
Separator plate AND2 捌きﾌﾟﾚｰﾄAND2
25 PCO VP0088 QSZ1 AD DJ D
Plate cover ﾌﾟﾚｰﾄｶﾊﾞｰ
26 MSP RC0270 QSZZ AB DJ C
Separator plate spring 捌きﾌﾟﾚｰﾄ
ｽﾌﾟﾘﾝｸﾞ
27 NKO M-0005 QSZZ AC DJ C
Cassette guide collar ｶｾｯﾄｶﾞｲﾄﾞｺﾛ
28 NSF TZ0048 QSPZ AF DS C
Cassette collar shaft ｶｾｯﾄｺﾛ軸
29 XBP S730P0 8KS0 AB DD C
Screw(3×8KS) ﾋﾞｽ
33 PSH EZ0301 QSZZ AC DJ C
Rail R side sheet F ﾚｰﾙ R ｻｲﾄﾞｼｰﾄ F
34 PSH EZ0302 QSZZ AC DJ C
Rail R side sheet R ﾚｰﾙ R ｻｲﾄﾞｼｰﾄ R
36 PSH EZ0463 QSZZ AD DJ C
Front separator sheet 前捌きｼｰﾄ
37 PSP O-0026 QSZZ AA DJ C
MF ACT cushion MF ACT ｽﾎﾟﾝｼﾞ
38 LHL DZ0094 QSZZ AC DJ C
PS pressure holder PS 加圧ﾎﾙﾀﾞｰ
39 MSP RC0292 QSZZ AC DJ C
PS follower connect spring PS 従動接続
ｽﾌﾟﾘﾝｸﾞ
40 MSP RD0287 QSZZ AC DJ C
Paper feed sub roller spring 給紙補助
ﾛｰﾗｰｽﾌﾟﾘﾝｸﾞ
41 NRO LP0087 QSZZ AD DJ C
Paper feed sub roller 給紙補助ﾛｰﾗｰ
42 NSF TZ0101 QSZZ AC DJ C
Paper feed sub roller shaft 給紙補助ﾛｰﾗｰ軸
43 PSH EZ0314 QSZ2 AF DS C
Toner protect sheet N ﾄﾅｰ飛散封止
ﾏｲﾗｰ N
44 LBR C-0012 QSZZ AD DJ C
Manual paper feed sub collar bracket 手差し補助ｺﾛ
ﾌﾞﾗｹｯﾄ
45 NKO M-0011 QSZZ AC DJ C
Manual paper feed sub collar 手差し補助ｺﾛ
46 NSF TZ0101 QSZZ AC DJ C
Paper feed sub roller shaft 給紙補助ﾛｰﾗｰ軸
47 MSP RD0340 QSZZ AC DJ C
Manual paper feed sub roller spring 手差し補助ｺﾛ
SP
48 XEB S730P0 8000 AC DD C
Screw(3×8) ﾋﾞｽ
51 LPL TM0396 QSZ1 AD DJ C
Separator guide plate 捌きｶﾞｲﾄﾌﾟﾚｰﾄ
52 LX- WZ0064 FCZZ AA DD C
Push nut(M3) ﾌﾟｯｼｭﾅｯﾄ
53 PGI DM0186 QSZZ AK DX D
Cover guide ｶﾊﾞｰｶﾞｲﾄﾞ
54 LPL TM6022 FCZZ AC DJ C
M4 plate N M4 ﾌﾟﾚｰﾄ N
501 CGI DM0067 RS5 6 -AXFG E
Base plate paper feed guide unit [Missing parts code] 台板給紙
ｶﾞｲﾄﾞﾕﾆｯﾄ
1st lot
502 CCO VP0053 RS5 5 -ASEZ E
Middle frame cover unit [Missing parts code] 中間ﾌﾚｰﾑ
ｶﾊﾞｰﾕﾆｯﾄ
1st lot
503 CCO VP0088 RS5 6 -ANEQ E
Plate cover unit [Missing parts code] ﾌﾟﾚｰﾄｶﾊﾞｰﾕﾆｯﾄ
1st lot
504 CPL TP0409 RS5 1 AN EG E
Separation plate unit 分離ﾌﾟﾚｰﾄﾕﾆｯﾄ
