AR-5726/5731 MAINTENANCE 8 - 18
Note: Check to confirm that the solenoid shaft is in the gate bracket,
and fix with the screw.
H. Laser unit
Note: Do not disassemble the LSU unit.
(1) LSU
1) Turn OFF the machine power, and disconnect the power plug from
the power outlet.
2) Remove the left cabinet and exit tray.
3) Disconnect the LSU connector, and remove the securing screws to
remove the LSU.
2
1
1
2
1
1
1
2
1
