Sharp AR-5726 - 光学ﾌﾚｰﾑ 1(Optical Frame 1)

– 11 –
Update : 2009/11/16
6
光学ﾌﾚｰﾑ 1(Optical frame 1)
NO.
PARTS CODE
Inter-
change
PRICE RANK
NEW
MARK
PART
RANK
DESCRIPTION
TR No.
Effective
time
Ex. Ja.
1 PWI R-0 006QSP Z AZ FQ C
MB wire F MB ﾜｲﾔｰ F
2 CDA IU0 012QS1 5 BG GT C
Optical base plate 光学台板
3 NPL YZ0 016QSZ Z AF DS C
Pulley 定ﾌﾟｰﾘｰ
4 NPL YZ0 006QSZ 1 AD DJ C
L pulley L ﾌﾟｰﾘｰ
5 XRE SP4 0-0500 0 AA DD C
E type ring(E4) E ﾘﾝｸﾞ
6 PWI R-0 005QSP 1 AZ FQ C
MB wire R MB ﾜｲﾔｰ R
7 CMI R-0 008QS3 6 BB GD E
2/3 mirror unit 2/3 ﾐﾗｰﾕﾆｯﾄ
8 CRE FL0 004QS3 8 -BRMJ E
Copy lamp unit [Missing parts code] ｺﾋﾟｰﾗﾝﾌﾟﾕﾆｯﾄ
1st lot
9 XBP S74 0P06K0 0 AA DD C
Screw(4×6K) ﾋﾞｽ
10 LHL DZ0056 QSZZ AC DJ C
Wire holder ﾜｲﾔｰﾎﾙﾀﾞｰ
11 LX- BZ0004 QSPZ AB DD C
Screw ﾋﾞｽ
12 LRA LM0007 QSZ1 AG DS C
MB-B rail R MB-B ﾚｰﾙ R
13 LRA LM0006 QSZZ AG DS C
MB-B rail F MB-B ﾚｰﾙ F
14 XBP S730P0 5K00 AA DD C
Screw(3×5K) ﾋﾞｽ
15 RMO TP0027 QSZZ BG GT B
Mirror motor ﾐﾗｰﾓｰﾀｰ
16 MSP RC0040 QSZZ AB DJ C
MB drive spring MB 駆動ｽﾌﾟﾘﾝｸﾞ
17 CPL TM0084 QS02 AK DX C
Mirror motor fixing plate ﾐﾗｰﾓｰﾀｰ取付板
18 PGU MS0002 QSPZ AL EB C
Protection rubber 防振ｺﾞﾑ
19 XBP S740P1 6KS0 AB DD C
Screw(4×16KS) ﾋﾞｽ
20 PGU MS0004 QSZZ AA DJ C
Table glass cushion ﾃｰﾌﾞﾙｶﾞﾗｽｸｯｼｮﾝ
21 XRE SP50-0 6000 AA DD C
E type ring(E5) E ﾘﾝｸﾞ
22 NBR GP0012 QSZZ AC DJ C
Winder bearing R 巻取り軸受 R
23 NPL YZ0004 QSZZ AG DX C
Winder drive shaft pulley 巻取り駆動軸
ﾌﾟｰﾘｰ
24 NPL YZ0031 QSZZ AL EB C
Winder pulley 巻取りﾌﾟｰﾘｰ
25 LX- BZ0049 FCPZ AB DD C
Screw ﾋﾞｽ
26 XPS SJ30-1 2000 AB DD C
Spring pin(φ3-12) ｽﾌﾟﾘﾝｸﾞﾋﾟﾝ
27 NSF TZ0028 QSZ1 AS EQ C
Winder drive shaft 巻取り駆動軸
28 LX- BZ0324 FCPZ AA DD C
Screw ﾋﾞｽ
29 NBL TT0002 QSZZ AH DX B
Winder drive belt 巻取り駆動ﾍﾞﾙﾄ
30 NGE RH0027 QSZZ AH DX C
Mirror motor idle gear ﾐﾗｰﾓｰﾀｰ
ｱｲﾄﾞﾙｷﾞﾔ
31 LX- WZ0119 FCP1 AC DD C
Washer ﾜｯｼｬ
32 XRE SP70-0 8000 AA DD C
E type ring(E7) E ﾘﾝｸﾞ
33 NBR GP0011 QSZZ AC DJ C
Winder bearing F 巻取り軸受 F
34 LX- BZ0082 QSPZ AA DD C
Screw(3×8) ﾋﾞｽ
35 PGI DM0108 QST1 AG DX C
Hinge guide L ﾋﾝｼﾞｶﾞｲﾄﾞ L
36 XHB S730P0 8000 AB DD C
Screw(3×8) ﾋﾞｽ
37 PGI DM0109 QST1 AG DX C
Hinge guide R ﾋﾝｼﾞｶﾞｲﾄﾞ R
38 LPL TM0497 QSZZ AG DS C
Panel support plate LN ﾊﾟﾈﾙ支持板 LN
39 LAN GF0021 QSZZ AF DS C
Panel reinforce angle R ﾊﾟﾈﾙ補強ｱﾝｸﾞﾙ
R
40 XHB S740P1 0000 AA DD C
Screw(4×10) ﾋﾞｽ
11
