– 7 –
Update : 2009/10/16
4
ﾌﾚｰﾑ部 (Frame section)
NO.
PARTS CODE
Inter-
change
PRICE RANK
NEW
MARK
PART
RANK
DESCRIPTION
TR No.
Effective
time
Ex. Ja.
1 LPL TM0 163QSZ Z AK EB C
Left reinforce plate lower 左補強板下
2 XHB S73 0P0800 0 AB DD C
Screw(3×8) ﾋﾞｽ
3 LPL TM0 232QSZ 2 AU EQ C
Frame reinforce plate R ﾌﾚｰﾑ補強板 R
4 CFR M-0 043QS0 3 AX FQ D
Corner frame RL ｺｰﾅｰﾌﾚｰﾑ RL
5 XEB S74 0P1000 0 AA DD C
Screw(3×10) ﾋﾞｽ
6 CPL TM0 529QS0 1 -AGDS C
DUP drive idle plate And2 Ref [Missing parts code] DUP 駆動ｱｲﾄﾞﾙ
ﾌﾟﾚｰﾄ And2 Ref
1st lot
7 PSH EZ0 507QSZ Z AA DJ C
Pulley flange sheet N ﾌﾟｰﾘｰﾌﾗﾝｼﾞ
ｼｰﾄ N
9 NPL YZ0 036QSZ Z AD DJ C
DUP idle pulley TLPD DUPｱｲﾄﾞﾙﾌﾟｰﾘｰ
TLPD
11 LDA I-0023 QSTE BG GT D
Base plate 台板
14 LHL DW1757 FCPZ AC DJ C
Wire saddle(HL-18-0) ﾜｲﾔｰｻﾄﾞﾙ
15 XHB S740P1 0000 AA DD C
Screw(4×10) ﾋﾞｽ
16 LPL TM0333 QSZ2 AX FG C
Frame reinforce plate F ﾌﾚｰﾑ補強板 F
18 XRE SP40-0 6000 AA DD C
E type ring(E4) E ﾘﾝｸﾞ
19 NBL TT0026 QSZZ AF DS B
DUP drive belt DUP 駆動ﾍﾞﾙﾄ
20 LPL TM0165 QSZ3 AS EZ C
Front reinforce plate 前補強板
21 PCO VP0110 QSZ1 AE DJ D
Interlock cover ｲﾝﾀｰﾛｯｸｶﾊﾞｰ
22 LPL TM0166 QSZZ AC DJ C
Front support adjusting plate 前支持調整板
23 CFR M-0044 QS03 BB FX C
Right frame unit 右ﾌﾚｰﾑﾕﾆｯﾄ
24 LPL TM0251 QSZ1 AE DS C
PS earth plate PS ｱｰｽ板
25 NSF TZ0048 QSPZ AF DS C
Cassette collar shaft ｶｾｯﾄｺﾛ軸
26 NKO M-0005 QSZZ AC DJ C
Cassette guide collar ｶｾｯﾄｶﾞｲﾄﾞｺﾛ
27 XBP S730P0 8KS0 AB DD C
Screw(3×8KS) ﾋﾞｽ
28 XHB S730P0 6000 AC DD C
Screw(3×6) ﾋﾞｽ
29 LAN GF0012 QSZZ AF DS C
Right reinforce angle (Japan) 右補強ｱﾝｸﾞﾙ
30 XBB S740P0 6000 AA DD C
Screw(4×6) (Japan) ﾋﾞｽ
40 PSH EZ0333 QSZZ AC DJ C
PS front sheet PS 前ｼｰﾄ
41 PSH EZ0325 QSZZ AB DJ C
Frame lower sheet ﾌﾚｰﾑ下ｼｰﾄ
42 CPL TM0342 QS01 AH DX C
DU motor fixing plate ASS’Y DU ﾓｰﾀｰ取付板
組品
43 NGE RH0174 QSZ1 AD DJ C
DUP drive gear TLPD DUP 駆動ｷﾞﾔ
TLPD
44 RMO TS0056 QSP1 -BDGJ B
DUP reverse motor [Missing parts code] DUP 反転ﾓｰﾀｰ
45 NBL TT0038 QSZZ AF DS B
DUP drive belt TL DUP 駆動ﾍﾞﾙﾄ
TL
46 LPL TM0332 QSZZ AE DJ C
Fusing unit earth plate 定着ﾕﾆｯﾄｱｰｽ板
47 LPL TM0495 QSZZ AE DJ C
Power supply switch fixing plate And2 Ref 電源ｽｲｯﾁ取付板
And2 Ref
48 XEB S740P1 2000 AA DD C
Screw(4×12) ﾋﾞｽ
55 PML T-0091 QSZ1 AD DJ C
Right frame cushion A 右ﾌﾚｰﾑﾓﾙﾄ A
56 PGS K-0044 QSPZ AH DX C
OP holder cushion [Except MX-M310FG] OP ﾎﾙﾀﾞｰｸｯｼｮﾝ
61 NPL YZ0015 QSZZ AC DJ C
Pulley(S2M20T) ﾌﾟｰﾘｰ
62 MSP RC1315 FCZ1 AD DJ C
Manual paper feed clutch spring A 手差しｸﾗｯﾁ
ｽﾌﾟﾘﾝｸﾞ A
63 NGE RH0066 QSZZ AD DJ C
1 way gear(17T) 1 ｳｪｲｷﾞﾔ
64 PSH EZ0432 QSZZ AA DJ C
PS front sheet 2 PS 前ｼｰﾄ 2
65 LBS HC0009 QSPZ AC DJ C
Edge bush(CE-012 L15) ｴｯｼﾞﾌﾞｼｭ
66 LHL DW1009 ACZZ AA DD C
Clamp(UAMS-05S-2) ｸﾗﾝﾌﾟ
67 PSH EZ0448 QSZZ AA DJ C
Optical bottom sheet And 光学底ﾏｲﾗｰ And
68 NFA NP0020 QSPZ AP EQ B
Fan motor ANR2 ﾌｧﾝﾓｰﾀｰ ANR2
69 XBP S730P3 0KS0 AC DD C
Screw(3×30KS) ﾋﾞｽ
70 CPL TM0530 QS01 -AFDS C
DUP drive rotation plate And2 Ref [Missing parts code] DUP駆動回転板
And2 Ref
1st lot
71 MSP RT0147 QSZZ AC DJ C
Stopper arm spring ｽﾄｯﾊﾟｰｱｰﾑ
ｽﾌﾟﾘﾝｸﾞ
72 LX- BZ0852 FCZZ AC DD C
Step screw 段ﾋﾞｽ
7
