Sharp AR-5726 - MX-Rp10 搬送部

– 63 –
Update : 2009/11/16
]
MX-RP10 搬送部 1(MX-RP10 Transport section 1)
NO.
PARTS CODE
Inter-
change
PRICE RANK
NEW
MARK
PART
RANK
DESCRIPTION
TR No.
Effective
time
Ex. Ja.
1 PGI DM0 107QSZ 1 AQ EQ C
Paper feed guide 給紙ｶﾞｲﾄﾞ
2 PSH EZ0 452QSZ Z AF DS C
Front separator sheet 前捌きｼｰﾄ
4 PSH EZ0 423QSZ Z AP EQ C
Separator sheet 捌きｼｰﾄ
5 LPL TP0 328QSZ Z AC DJ C
SPF separator plate SPF 捌き板
6 MSP RC0 321QSZ 1 AB DJ C
Pressure spring 圧力ｽﾌﾟﾘﾝｸﾞ
7 PSH EZ0 451QSZ Z AC DJ C
Sound proof sheet 前捌き消音ｼｰﾄ
9 LPL TM0 327QSZ Z AD DJ C
Sound proof plate 消音板
11 XHB S730P0 8000 AB DD C
Screw(3×8) ﾋﾞｽ
12 NRO LR0096 QSZZ AR EQ B
Transport roller 搬送ﾛｰﾗｰ
13 NRO LR0131 QSZZ AP EQ B
PS roller SPF PS ﾛｰﾗｰ SPF
14 NRO LR0095 QSZZ AR EQ B
Read front roller 読取前ﾛｰﾗｰ
15 PSH EP0647 QSZZ AD DJ C
White sheet AN2R 白ﾏｲﾗｰ AN2R
16 LPL TM0325 QSZZ AH DX C
Transport plate 搬送板
17 MSP RC0360 QSZZ AC DJ C
Delivery paper guide spring R 排紙ｶﾞｲﾄﾞ
ｽﾌﾟﾘﾝｸﾞ R
18 DHA I-0467 QSZZ AP EQ C
RSPF harness RSPF ﾊｰﾈｽ
19 RDT CT0006 QSPZ AX FG B
Paper feed in detect sensor 入紙検知ｾﾝｻｰ
20 PTM E-0030 QSZZ AC DJ C
Open/close lock pawl TLPD 開閉ﾛｯｸ爪 TLPD
21 MSP RC3356 FCZZ AA DJ C
Lock spring ﾛｯｸｽﾌﾟﾘﾝｸﾞ
22 NBR GM0501 FCZZ AB DJ C
Bearing 軸受
23 XRE SP50-0 6000 AA DD C
E type ring(E5) E ﾘﾝｸﾞ
24 XPS SP20-0 9000 AA DD C
Spring pin(φ2-9) ｽﾌﾟﾘﾝｸﾞﾋﾟﾝ
25 NPL YZ0019 QSZZ AE DJ C
PS pulley PS ﾌﾟｰﾘｰ
26 PSH EP3029 FCZZ AA DD C
Flange sheet DUP2 ﾌﾗﾝｼﾞｼｰﾄ DUP2
27 LHL DZ0102 QSZ1 AC DJ C
Tension holder F ﾃﾝｼｮﾝﾎﾙﾀﾞｰ F
28 XEB S730P0 8000 AC DD C
Screw(3×8) ﾋﾞｽ
29 NKO M-0007 QSZZ AC DJ C
Tension roller ﾃﾝｼｮﾝｺﾛ
30 MLE VP0095 QSZZ AD DJ C
Book sensor actuator TLPD ﾌﾞｯｸｾﾝｻｰ
ｱｸﾁｭｴｰﾀｰ TLPD
32 VHP SG2481 ++-1 AE DS B
Photo sensor(SG2481) ﾌｫﾄｾﾝｻｰ
33 XEB S740P1 4000 AB DD C
Screw(4×14) ﾋﾞｽ
34 MSP RC0153 QSZZ AB DJ C
Book sensor spring ﾌﾞｯｸｾﾝｻｰ
ｽﾌﾟﾘﾝｸﾞ
35 XWV S740-0 5000 AA DD C
Washer ｷｸﾜｯｼｬｰ
36 LPL TP0434 QSZZ AC DJ C
Book sensor fixing plate B1A ﾌﾞｯｸｾﾝｻｰ
取付板 B1A
37 JKN BZ0009 QSZZ AE DJ D
JAM release knob(24P) JAM 解除ﾉﾌﾞ
38 NBL TT0036 QSZZ AF DS B
Belt(B79MXL4.0) ﾍﾞﾙﾄ
39 NBR GC0017 QSZZ AC DJ C
Bearing 軸受
40 MSP RD0316 QSZZ AC DJ C
Tension spring F ﾃﾝｼｮﾝｽﾌﾟﾘﾝｸﾞ F
41 LPL TP0324 QSZZ AH DX C
Revers gate plate 反転ｹﾞｰﾄ板
42 NRO LR0097 QSZZ AR EQ B
Delivery paper roller 排紙ﾛｰﾗｰ
43 LPL TM0326 QSZZ AM EG C
Paper feed paper guide reinforce plate 給紙
ﾍﾟｰﾊﾟｰｶﾞｲﾄﾞ
補強板
44 PBR SS0008 QSZ1 AH DX B
Discharge brush 除電ﾌﾞﾗｼ
45 PGI DM0106 QSZ1 AU EZ C
Transport R paper guide 搬送 R
ﾍﾟｰﾊﾟｰｶﾞｲﾄﾞ
46 PSH EZ0454 QSZZ AB DJ C
Paper feed paper guide cushion R 給紙
ﾍﾟｰﾊﾟｰｶﾞｲﾄﾞ
ｸｯｼｮﾝ R
47 PSH EZ0455 QSZZ AD DJ C
Paper feed paper guide sound proof cushion 給紙
ﾍﾟｰﾊﾟｰｶﾞｲﾄﾞ
消音ｸｯｼｮﾝ
48 MSP RC0063 QSZZ AB DJ C
Delivery paper guide spring 排紙
ﾍﾟｰﾊﾟｰｶﾞｲﾄﾞ
ｽﾌﾟﾘﾝｸﾞ
49 LX- WZ5002 BCZZ AA DD C
Poly slider(6.2-12-0.5) ﾎﾟﾘｽﾗｲﾀﾞｰ
501 CGI DM0106 RS5 3 -BXTF E
SPF Transport unit [Missing parts code] 搬送ﾕﾆｯﾄ RSPF
(Include Block 34-501,Without No.18) ( ﾌﾞﾛｯｸ 34-501
含む。
No.18 除く )
1st lot
63
